CY8CKIT-002, as shipped from the factory, is verified to meet with requirements of CE as a Class A product. The CY8CKIT-002 boards are sensitive to electrostatic discharge (ESD).
Page 6
Safety Information CY8CKIT-002 MiniProg3 User Guide, Doc. # 001-59350 Rev. *E...
Software CD ■ Quick start guide ■ The CY8CKIT-002 CD installs critical information, such as the kit documentation, which includes the user guide and release notes, in the following project directory: [Install path]\Cypress\CY8CKIT-002 MiniProg3 Programming The MiniProg3 programmer/debugger provides the flexibility to work with different programming and debugging interfaces, such as JTAG, SWD, ISSP, and I C.
Courier New C:\...cd\icc\ Displays file names and reference documentation: Italics Read about the sourcefile.hex file in the PSoC Designer User Guide. Displays keyboard commands in procedures: [Bracketed, Bold] [Enter] or [Ctrl] [C] CY8CKIT-002 MiniProg3 User Guide, Doc. # 001-59350 Rev. *E...
Page 9
Click the File menu, and then click Open. Displays an equation: Times New Roman 2 + 2 = 4 Text in gray boxes Describes cautions or unique functionality of the product. CY8CKIT-002 MiniProg3 User Guide, Doc. # 001-59350 Rev. *E...
Adobe Reader (to view.PDF documents) MiniProg3 Figure 2-1. Top View Busy LED USB MiniProg3 10-pin JTAG/SWD Target Power LED Connector Connector 5-pin ISSP/I2C/SWD Connector Aux LED Status LED Figure 2-2. Bottom View CY8CKIT-002 MiniProg3 User Guide, Doc. # 001-59350 Rev. *E...
PSoC Programmer window turns green and shows Connected. You can now use MiniProg3 and the functions it supports. For more information on how to use PSoC Programmer, see the PSoC Programmer User Guide. CY8CKIT-002 MiniProg3 User Guide, Doc. # 001-59350 Rev. *E...
Middle - No Label (Yellow): Flashes briefly during the initial configuration of the device. If it stays ■ lit, this LED indicates that a configuration error has occurred. If this happens, disconnect the MiniProg3 from the USB port and then reconnect it. CY8CKIT-002 MiniProg3 User Guide, Doc. # 001-59350 Rev. *E...
Target Board Table 3-1. Connectors / Communication Protocol Support Connector ISSP JTAG SWD and SWV 5-pin Supported Supported 10-pin Supported SWD and SWV a. SWV trace is available only with SWD debugging. CY8CKIT-002 MiniProg3 User Guide, Doc. # 001-59350 Rev. *E...
JTAG devices. The MiniProg3 supports programming and debugging the PSoC 3 and PSoC 5LP devices using JTAG, through the 10-pin connector only. 3.1.3 SWD/SWV Recent ARM-based devices have introduced a new serial debugging standard called Serial Wire CY8CKIT-002 MiniProg3 User Guide, Doc. # 001-59350 Rev. *E...
When programming JTAG devices, note that MiniProg3 does not support nTRST pins. Figure 3-3. 10-Pin Connector with Pin Assignments Note The ribbon cable connector XRES extends beyond the body of the connector. Be sure to allow room. VTARG VTARG Pin 1 CY8CKIT-002 MiniProg3 User Guide, Doc. # 001-59350 Rev. *E...
For PSoC 3 and PSoC 5LP, this is the Vddio1 supply because this supply is used to drive the debug pins. If you do not connect the VTARG or you connect it to the wrong supply, MiniProg3 cannot communicate with the target device. CY8CKIT-002 MiniProg3 User Guide, Doc. # 001-59350 Rev. *E...
MiniProg3 revision, either *A or *B, is shown on the sticker on the back of the device.) Regulatory Compliance Information The CY8CKIT-002 complies with the CE-Low Voltage Directive 2006/95/EC (Europe) safety requirement. It has been tested and verified to comply with the following electromagnetic compatibility (EMC) regulations.
