Please note that Cypress is an Infineon Technologies Company.
The document following this cover page is marked as "Cypress" document as this is the
company that originally developed the product. Please note that Infineon will continue
to offer the product to new and existing customers as part of the Infineon product
portfolio.
Continuity of document content
The fact that Infineon offers the following product as part of the Infineon product
portfolio does not lead to any changes to this document. Future revisions will occur
when appropriate, and any changes will be set out on the document history page.
Continuity of ordering part numbers
Infineon continues to support existing part numbers. Please continue to use the
ordering part numbers listed in the datasheet for ordering.
www.infineon.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cypress Semiconductor F2MC-16FX Series
Summary of Contents for Cypress Semiconductor F2MC-16FX Series
- Page 1 Please note that Cypress is an Infineon Technologies Company. The document following this cover page is marked as “Cypress” document as this is the company that originally developed the product. Please note that Infineon will continue to offer the product to new and existing customers as part of the Infineon product portfolio.
- Page 2 MB2198-763-01-E/02-E MC-16FX Family MB96630 Evaluation Board Operation Guide Doc. No. 002-05597 Rev. *A Cypress Semiconductor 198 Champion Court San Jose, CA 95134-1709 Phone (USA): 800.858.1810 Phone (Intnl): +1 408.943.2600 www.cypress.com...
- Page 3 Copyrights © Cypress Semiconductor Corporation, 2012-2016. This document is the property of Cypress Semiconductor Corporation and its subsidiaries, including Spansion LLC (“Cypress”). This document, including any software or firmware included or referenced in this document (“Software”), is owned by Cypress under the intellectual property laws and treaties of the United States and other countries worldwide.
- Page 4 Preface This document indicates directions for use about the "MB96630 evaluation board" which is the evaluation environment of MB96630 series of a F MC -16FX-16bit microcontroller *: Refer to MCU below. Using the product safely This manual contains important information for using this product safely. Be sure to read this manual before using the product, and to follow the directions given in this manual in order to use the product correctly.
- Page 5 Preface Target products The available products with this evaluation board are shown below. Series Product Number (not included Package suffix) MB96F633R, MB96F633A MB96F635R, MB96F635A MB96630 MB96F636R MB96F637R Caution of the product described in this manual The following precautions apply to the product described in this manual. Indicates a potentially hazardous situation which could result in death or serious injury and/or a fault in the WARNING user’s system if the product is not used correctly.
-
Page 6: Table Of Contents
Contents Overview ..................................6 Function overview ..............................7 Block diagram ................................ 9 Function details ................................10 Power supply settings ............................10 Sub clock settings ..............................11 UART ch.0 select jumper ............................. 13 Mode SW settings ............................... 14 OCD (On chip debugger) interface ........................15 Other jumper settings ............................ -
Page 7: Overview
1. Overview The MB96630 Evaluation Board provides the evaluative environment of the MB96630 series MCU. The following shows the MB96630 evaluation board. Figure 1-1. MB96630 Evaluation Board MB2198-763-01-E/02-E F MC-16FX Family MB96630 Evaluation Board Operation Guide, Doc. No. 002-05597 Rev. *A... -
Page 8: Function Overview
Overview 1.1 Function overview This board can mount MCU (with or without socket). The location of the main function is shown as follows. Figure 1-2. MB96630 Evaluation Board function overview RS/USB monitor xtal Main/Sub connector (solder side) Main xtal Mode socket monitor monitor... - Page 9 Overview Table 1-1. MB96630 Evaluation Board function list Function Specification Remarks with socket MB96F630 NQPACK080SD with socket or direct mounted HQPACK080SD Main clock 4MHz Oscillator with socket Sub clock 32.768kHz External power supply External power supply connection pin connection (DC3.3V to 5.0V) OCD debugger(MB2100-01-E) OCD connector Connection...
-
Page 10: Block Diagram
Overview 1.2 Block diagram The block diagram of this board is shown below. Figure 1-3. MB96630 Evaluation Board Block Diagram OCD connector 4MHz Main board DC12V→ ・DC5V 5.0V 32kHz ・DC3.3V (MB96630) 3.3V With Socket 80 MODE SW RS ch0 Monitor USART ch0 land USART ch7... -
Page 11: Function Details
2. Function details The function details of this board are shown as follows. 2.1 Power supply settings Confirm the following jumpers are closed. (J2, J4, J5, J14) Figure 2-1. Power supply jumpers location AVCC AVSS VCC_MCU AVRH MB2198-763-01-E/02-E F MC-16FX Family MB96630 Evaluation Board Operation Guide, Doc. No. 002-05597 Rev. *A... -
Page 12: Sub Clock Settings
Function details Table 2-1. Power supply jumpers function Jumper Function Setting [VCC_MCU] Short-circuit (default) : ON Power supply for VCC pin Open : OFF [AVRH] Short-circuit (default) : ON Power supply for AVRH pin Open : OFF [AVCC] Short-circuit (default) : ON Power supply for AVCC pin Open : OFF [AVSS]... - Page 13 Function details Table 2-2. J7 setting Setting X1A connection select X1A connect to sub clock (default) X1A connect to Q120 Table 2-3. J24 setting Setting X0A connection select X0A connect to GND X0A connect to sub clock (default) X0A connect to Q119 MB2198-763-01-E/02-E F MC-16FX Family MB96630 Evaluation Board Operation Guide, Doc.
-
Page 14: Uart Ch.0 Select Jumper
Function details 2.3 UART ch.0 select jumper The connection destination of the UART ch.0 signal can be selected by J20/J21. These jumpers location and settings are shown below. Figure 2-3. UART ch.0 select jumper location From right to left 1, 2, 3 J20:TX , J21:RX Table 2-4. -
Page 15: Mode Sw Settings
Function details 2.4 Mode SW settings The selection of the operational mode of MCU can be set by SW1 as follows. The mode switch location and settings are shown below. Figure 2-4. Mode SW location Mode SW bit1:MD , bit2:DEBUG Table 2-5. -
Page 16: Ocd (On Chip Debugger) Interface
Function details 2.5 OCD (On chip debugger) interface The MB96630 evaluation board can operate software "Softune" for debugging by connecting Cypress OCD-E (on chip debugger). The OCD connector location and settings are shown below. Figure2-5 OCD cable connect location connector Figure2-6 How to connect OCD-E Turn the coaxial cable appended to Cypress OCD- E(MB2100-01-E) as shown in a left chart. -
Page 17: Other Jumper Settings
Function details 2.6 Other jumper settings These jumpers in the table can control the connection between the MCU pin and the peripheral I/O. Table 2-6. Signal connection jumpers location Jumper Signal RS I/F ch.0 (USB): RX RS I/F ch.0(USB): TX RS I/F ch.1 : RX RS I/F ch.1 : TX LIN I/F ch.0 : RX... -
Page 18: Signal Monitor
Function details 2.7 Signal monitor The correspondence of the signal monitor land and the MCU pin number is shown as follows. (Q numbers are equal to MCU pin numbers.) Table 2-7. Monitor land list Pin No. Pin No. Pin No. Pin No. -
Page 19: Main Board Connection
Function details 2.8 Main board connection The connection of MCU and I/O on the main board is shown below. General-purpose LED The correspondence table for the general-purpose LED mounted on the main board and the MCU pin number is shown below. - Page 20 Function details NMI SW The correspondence of NMI SW mounted on the main board and the MCU pin number is shown below. Table 2-10. NMI switch MB96630 NMI SW Parts number Pin number Pin name Reset SW The correspondence of RESET SW mounted on the main board and the MCU pin number is shown below. Table 2-11.
-
Page 21: Power-On
3. Power-ON Basically, this board cannot turn on the power supply alone. Mount on the main board (MB2198-760-E) and use it. 3.1 FOR TEST USE ONLY, External power supply connection pin This board has the external power supply connection pin for test use. (VCC = 3.3V to 5.0V) When you connect an external power supply to this pin, and you use alone this board, short-circuit J22 (DVCC) and J23 (AVCC). -
Page 22: Circuit Diagram
4. Circuit diagram MB2198-763-01-E/02-E F MC-16FX Family MB96630 Evaluation Board Operation Guide, Doc. No. 002-05597 Rev. *A... -
Page 23: Recycling
Valid for European Union Countries: According to the European WEEE-Directive and its implementation into national laws we take this device back. For disposal please send the device to the following address: Cypress Semiconductor Europe GmbH Warehouse / Disposal Monzastraße 4a 63225 Langen Gültig für EU-Länder:... -
Page 24: China-Rohs Regulation
6. China-RoHS Regulation Compliance with Administration on the Control of Pollution Caused by Electronic Information Products of the People’s Republic of China 这标记是按照2006年2月28日公布的[电子信息产品污染控制管理办法]以及SJ/T11364-2006[电子信息产品 污染控制标识要求]在中国销售的电子信息产品的环保使用期限。如遵守关于这产品的安全或使用上的注意 ，在这期限内(从生产日期起算)不会因产品中的有害物质漏到外部、或发生突然变异，而引起环境污染和对 人体或财产的重大影响。 产品中有毒有害物质或元素的名称及含量 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷线路板... -
Page 25: Revision History
Revision History Document Revision History Document Title: MB2198-763-01-E/02-E F MC-16FX Family MB96630 Evaluation Board Operation Guide Document Number: 002-05597 Revision Issue Date Origin of Description of Change Change 11/14/2012 MITK Initial release 04/29/2016 MITK Migrated Spansion Guide from SS704-00003-1v0-E to Cypress format MB2198-763-01-E/02-E F MC-16FX Family MB96630 Evaluation Board Operation Guide, Doc.
