Your Phone
Figure 3: Wired Expansion Microphone Installation
Related Topics

Install the Wireless Expansion Microphones

The conference phone provides the option of connecting two wireless expansion microphones.
Note You must use either two wired microphones or two wireless microphones with the phone, but not a mixed
combination.
When the phone is in a call, the LED on the expansion microphone is lit green. To mute the expansion
microphone, press the Mute key. When the microphone is muted, the LED is lit red. When the battery in the
microphone is low, the battery indication LED blinks rapidly.
Before you begin
Disconnect the wired expansion microphones before you install wireless expansion microphones. You cannot
use both wired and wireless expansion microphones at the same time.
Procedure
Step 1
Position the table mount plate on the table surface location where you want to place the microphone.
Step 2 Remove the adhesive for the double-stick tape on the bottom of the table mount plate. Place the table mount
plate to adhere to the table surface.
Step 3
Attach the microphone to the table mount plate. Magnets are embedded in the microphone to snap the unit
into place.
Wired Expansion Microphone, on page 13
Cisco IP Conference Phone 8832 Multiplatform Phone User Guide
Install the Wireless Expansion Microphones
