This user's guide describes the characteristics, operation, and use of the OPT3004EVM evaluation
module. It discusses how to set up and configure the software and hardware, and reviews various aspects
of the program operation. Throughout this document, the terms evaluation board, evaluation module, and
EVM are synonymous with the OPT3004EVM. This document also includes an electrical schematic,
printed circuit board (PCB) layout drawings, and a parts list for the EVM.
SBOU220 – December 2018
Submit Documentation Feedback
OPT3004EVM User's Guide
Copyright © 2018, Texas Instruments Incorporated
User's Guide
SBOU220 – December 2018
OPT3004EVM User's Guide
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Texas Instruments OPT3004EVM
Summary of Contents for Texas Instruments OPT3004EVM
- Page 1 SBOU220 – December 2018 OPT3004EVM User's Guide This user’s guide describes the characteristics, operation, and use of the OPT3004EVM evaluation module. It discusses how to set up and configure the software and hardware, and reviews various aspects of the program operation. Throughout this document, the terms evaluation board, evaluation module, and EVM are synonymous with the OPT3004EVM.
-
Page 2: Table Of Contents
Hardware Included with OPT3004EVM Kit ................... OPT3004EVM Hardware Setup ..................OPT3004 Test Board Block Diagram ....................Typical Hardware Connection ..........Typical Response After Connecting OPT3004EVM to the Computer ................OPT3001EVM Software-Installation Files ................OPT3001EVM Software-Installation Launch ................OPT3001EVM Software-Installation Prompts .................. -
Page 3: Overview
I C protocol making it ideal for many applications. The OPT3004EVM is a platform for evaluating the performance of the OPT3001 under various conditions. The OPT3004EVM consists of two PCBs. The first is the SM-USB-DIG board that communicates with the computer, provides power, and sends and receives appropriate digital signals. -
Page 4: Related Documentation From Texas Instruments
The following documents provide information regarding Texas Instruments' integrated circuits used in the assembly of the OPT3004EVM. This user's guide is available from the TI web site under literature number SBOU220. Any letter appended to the literature number corresponds to the document revision that is current at the time of the writing of this document. -
Page 5: Theory Of Operation For The Opt3004Evm
Figure 3. OPT3004 Test Board Block Diagram OPT3004EVM Hardware Overview If not already assembled, the basic hardware setup for the OPT3004EVM involves connecting the OPT3004 test board to the SM-USB-DIG Platform and then connecting the USB cable. This section presents the details of this procedure. -
Page 6: Typical Hardware Connection
® Figure 5. Typical Response After Connecting OPT3004EVM to the Computer In some cases, the Add Hardware Wizard appears. If this installation prompt occurs, allow the device manager to install the human interface device drivers by clicking Yes at each request to install the drivers. -
Page 7: Opt3004Evm Software
OPT3004EVM Software www.ti.com OPT3004EVM Software This section describes the installation and operation of the OPT3004EVM software. The OPT3004EVM usese the OPT3001EVM Software. Hardware Requirements The OPT3001EVM software has been tested on the Windows 7 operating system (OS) with United ®... -
Page 8: Opt3001Evm Software-Installation Launch
Follow the prompts as shown in Figure 8 to install the OPT3001EVM software. Figure 8. OPT3001EVM Software-Installation Prompts The OPT3001EVM GUI software is now installed. OPT3004EVM User's Guide SBOU220 – December 2018 Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... -
Page 9: Launching The Opt3001Evm Software
If the message shown in Figure 10 appears when the OPT3001EVM GUI software is launched, disconnect all components of the OPT3004EVM kit, and repeat the hardware assembly and connection instructions. Figure 10. Hardware Error Message SBOU220 – December 2018 OPT3004EVM User's Guide Submit Documentation Feedback Copyright ©... -
Page 10: Opt3001Evm Software Operation
This section primarily discusses how to operate the OPT3001EVM software. The GUI has a primary window that is used to configure and read from the OPT3004EVM, along with two other windows that are used to access different features of the OPT3004EVM. Basic GUI functionality and a description of the tabs are also presented in this section. -
Page 11: C Address Selection
Figure 13. Click the Read Reg x00 button to update these fields and the plot with the latest values from the OPT3004EVM. Figure 13. Register x00 Button and Recorded Values Register x01 configures the OPT3004 and provides feedback about the state of the device; the bit names... -
Page 12: Registers X02 And X03 Lux Limit Controls
The low limit (darkest backlight) is always 0, and the high limit (brightest backlight) can be adjusted with the Lux for White numeric field. Figure 16. Simulated Screen Backlight Dimmer OPT3004EVM User's Guide SBOU220 – December 2018 Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... -
Page 13: Lux Vs. Sample Number Plot
Figure 18. Access the plot axis range and formatting by right-clicking the plot. Figure 17. Lux vs. Sample Number Plot Figure 18. Re-Initialize Button SBOU220 – December 2018 OPT3004EVM User's Guide Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... -
Page 14: Data Logging Setup And Enable
Figure 20. Read All Button on the Register Map Tab with Example Output OPT3004EVM User's Guide SBOU220 – December 2018 Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... -
Page 15: Schematic, Pcb Layout, And Bill Of Materials
Also, no additional LEDs are installed on the test board to reduce total ambient light around the device. The back side of the board is mostly planar; mounting holes are included to accommodate evaluation. SBOU220 – December 2018 OPT3004EVM User's Guide Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... -
Page 16: Pcb Layout
Figure 25 show the assembly drawings of the top and bottom PCB layers, respectively. Figure 22. PCB Top Layer Figure 23. PCB Bottom Layer OPT3004EVM User's Guide SBOU220 – December 2018 Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... -
Page 17: Bill Of Materials
Figure 24. PCB Top-Layer Assembly Drawing Figure 25. PCB Bottom-Layer Assembly Drawing Bill of Materials Table 3 lists the bill of materials for the OPT3004 test board. SBOU220 – December 2018 OPT3004EVM User's Guide Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... - Page 18 RES, 10k ohm, 5%, 0.125W, 0805 CRCW080510K0JNEA Vishay Dale RES, 0 ohm, 5%, 0.125W, 0805 CRCW08050000Z0EA Vishay Dale Ambient Light Sensor, DNP0006A OPT3004DNP Texas Instruments OPT3004EVM User's Guide SBOU220 – December 2018 Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated...
- Page 19 STANDARD TERMS FOR EVALUATION MODULES Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms set forth herein.
- Page 20 FCC Interference Statement for Class B EVM devices NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 21 【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの 措置を取っていただく必要がありますのでご注意ください。 1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用 いただく。 2. 実験局の免許を取得後ご使用いただく。 3. 技術基準適合証明を取得後ご使用いただく。 なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。 上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ ンスツルメンツ株式会社 東京都新宿区西新宿６丁目２４番１号 西新宿三井ビル 3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page 電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧ください。http:/ /www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page 3.4 European Union 3.4.1 For EVMs subject to EU Directive 2014/30/EU (Electromagnetic Compatibility Directive): This is a class A product intended for use in environments other than domestic environments that are connected to a low-voltage power-supply network that supplies buildings used for domestic purposes.
- Page 22 Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief in any United States or foreign court. Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2018, Texas Instruments Incorporated...
- Page 23 TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable warranties or warranty disclaimers for TI products. Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2018, Texas Instruments Incorporated...
