Connecting an Unbalanced Stereo Audio Source to the
FC-102Net Input
Figure 6 illustrates the pinout for connecting an unbalanced stereo audio source to the input:
Figure 6: Connecting an Unbalanced Stereo Audio Source to the Input

Connecting to FC-101Net / FC-102Net via RS-232

You can connect to the
connection and
8
Connect the RS-232 terminal block on the rear panel of the
follows:
From the RS-232 9-pin D-sub serial port connect:
•
Pin 2 to the TX pin on the
RS-232 terminal block.
•
Pin 3 to the RX pin on the
RS-232 terminal block.
•
Pin 5 to the G pin on the
232 terminal block.
FC-101Net, FC-102Net – Connecting the Devices
FC-101Net (the same applies to FC-102Net) via an RS-232
using, for example, a PC.
18
FC-101Net
FC-101Net
FC-101Net RS-
Kramer Electronics Ltd.
FC-101Net to a PC/controller, as
