Page 1: User Manual
K R A ME R E LE CT R O N IC S L TD . USER MANUAL MODEL: FC-1DGH DGKat to HDBT Converter P/N: 2900-300279 Rev 1... -
Page 4: Table Of Contents
Wiring the DGKat TP RJ-45 Connectors Technical Specifications Figures Figure 1: FC-1DGH DGKat to HDBT Converter Front Panel Figure 2: FC-1DGH DGKat to HDBT Converter Rear Panel Figure 3: Connecting the FC-1DGH DGKat to HDBT Converter Figure 4: FC-1DGH Rear Panel DIP-switch Figure 5: TP Pinout Wiring FC-1DGH –... -
Page 5: Introduction
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Products; GROUP 12: Digital Signage; and GROUP 13: Audio. Congratulations on purchasing your Kramer FC-1DGH DGKat to HDBT Converter, which is ideal for the following typical applications: ... -
Page 6: Getting Started
Avoid interference from neighboring electrical appliances that may adversely influence signal quality Position your Kramer FC-1DGH away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. -
Page 7: Recycling Kramer Products
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/. -
Page 8: Overview
Overview The FC-1DGH is a DGKat and Ethernet to HDBaseT converter. The FC-1DGH lets you connect any DGKat device and your Ethernet LAN over an extended distance to any HDBaseT compatible receiver, (for example, a projector with an HDBaseT input). -
Page 9: Defining The Fc-1Dgh
Defining the FC-1DGH defines the front panel of the FC-1DGH DGKat to HDBT Converter. Figure 1 Figure 1: FC-1DGH DGKat to HDBT Converter Front Panel Feature Function ETHERNET RJ-45 Connect to the Ethernet LAN Connector STATUS LED Lights yellow/green when there is a DGKat signal present. -
Page 10: Connecting The Fc-1Dgh
Figure 3: Connecting the FC-1DGH DGKat to HDBT Converter To connect the FC-1DGH as illustrated in the example in Figure 3 1. Connect a video and audio source, (for example, a laptop) to the DisplayPort and Audio In connectors on the SID-X1N. - Page 11 5. Connect the Ethernet LAN to the Ethernet RJ-45 connector on the FC-1DGH. 6. Connect the HDBT OUT RJ-45 connector on the FC-1DGH to the HDBT IN RJ-45 connector on the HDBT acceptor, (for example, a projector). FC-1DGH - Connecting the FC-1DGH...
-
Page 12: Configuring The Fc-1Dgh
Configuring the FC-1DGH The Setup DIP-switch on the rear panel is used to control the behavior of the device. Figure 4: FC-1DGH Rear Panel DIP-switch The following table describes the functions of the 4-way DIP-switch. Switch Function Setting EDID control Down—Passes the EDID (default) -
Page 13: Wiring The Dgkat Tp Rj-45 Connectors
Green / White Blue Blue / White Green Brown / White Brown Pair 1 4 and 5 Pair 2 1 and 2 Pair 3 3 and 6 Pair 4 7 and 8 FC-1DGH - Wiring the DGKat TP RJ-45 Connectors... -
Page 14: Technical Specifications
COMPLIANCE: ENVIRONMENTAL Complies with appropriate requirements of RoHs and REGULATORY COMPLIANCE: WEEE INCLUDED ACCESSORIES: Power supply RK-3T 19” rack adapter OPTIONS: WARRANTY: 7 years parts and labor http://www.kramerelectronics.com Specifications are subject to change without notice at FC-1DGH - Technical Specifications... - Page 16 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
