NANO-ULT5 SBC
NANO-ULT5 CPU Card
MODEL:
NANO-ULT5
EPIC SBC with 14nm Intel® Core™ i7/i5/i3 or Celeron® On-board SoC,
LVDS, HDMI, DP, Dual PCIe GbE, USB 3.1 Gen 2, M.2, PCIe Mini,
SATA 6Gb/s, RS-232/422/485, Audio, TPM and RoHS
User Manual
Page I
Rev. 1.00 - May 21, 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NANO-ULT5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology NANO-ULT5

Summary of Contents for IEI Technology NANO-ULT5

  • Page 1 NANO-ULT5 SBC NANO-ULT5 CPU Card MODEL: NANO-ULT5 EPIC SBC with 14nm Intel® Core™ i7/i5/i3 or Celeron® On-board SoC, LVDS, HDMI, DP, Dual PCIe GbE, USB 3.1 Gen 2, M.2, PCIe Mini, SATA 6Gb/s, RS-232/422/485, Audio, TPM and RoHS User Manual Page I Rev.
  • Page 2 NANO-ULT5 SBC Revision Date Version Changes May 21, 2019 1.00 Initial release Page II...
  • Page 3 NANO-ULT5 SBC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 NANO-ULT5 SBC Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Table Of Contents

    PTIONAL TEMS 3 CONNECTORS ......................14 3.1 P ..............15 ERIPHERAL NTERFACE ONNECTORS 3.1.1 NANO-ULT5 Layout ..................15 3.1.2 Peripheral Interface Connectors ..............16 3.1.3 External Interface Panel Connectors ............... 17 3.2 I ..............18 NTERNAL ERIPHERAL ONNECTORS 3.2.1 Audio Connector ....................18 3.2.2 Battery Connector ....................
  • Page 6 NANO-ULT5 SBC 3.2.2 M.2 Slot, M-key ....................30 3.2.1 DDR4 SO-DIMM Sockets ................32 3.2.2 PCIe Mini Card Slot, Full-size ................ 32 3.2.3 Power Connector ..................... 34 3.2.4 Power Button Connector .................. 35 3.2.5 Reset Button Connector ................... 36 3.2.6 RS-232 Serial Port Connector ................. 37 3.2.7 RS-422/485 Serial Port Connector ..............
  • Page 7 NANO-ULT5 SBC 4.7.4 LVDS Panel Resolution Select Switch ............. 65 4.8 C .................... 67 HASSIS NSTALLATION 4.8.1 Heat Spreader ....................67 4.8.1 Motherboard Installation Example ..............68 4.9 I ............69 NTERNAL ERIPHERAL EVICE ONNECTIONS 4.9.1 AT Power Connection ..................69 4.9.2 Audio Kit Installation ..................
  • Page 8 NANO-ULT5 SBC 5.3.2 IEI Feature ....................... 98 5.4 C ........................99 HIPSET 5.4.1 System Agent (SA) Configuration ..............99 5.4.1.1 Memory Configuration ................100 5.4.1.2 Graphics Configuration ................101 5.4.2 PCH-IO Configuration .................. 103 5.4.2.1 PCI Express Configuration ..............105 5.4.2.1.1 M2_A1 / MINI_PCIE1 / M2_M2 Configuration ........
  • Page 9 NANO-ULT5 SBC List of Figures Figure 1-1: NANO-ULT5 ......................... 2 Figure 1-2: Connectors ........................4 Figure 1-3: Dimensions (mm) ......................5 Figure 1-4: Data Flow Diagram ...................... 6 Figure 3-1: Connector and Jumper Locations ................15 Figure 3-2: Audio Connector Location ..................18 Figure 3-3: Battery Connector Location ..................
  • Page 10 NANO-ULT5 SBC Figure 3-28: DisplayPort Connector Pinout Locations ............. 47 Figure 3-29: HDMI Connector Pinout Locations ................ 48 Figure 3-30: LAN Connector ......................49 Figure 3-31: Serial Port Pinouts ....................50 Figure 3-32: USB 3.1 Gen 2 Port Pinouts ................... 51 Figure 4-1: SO-DIMM Installation ....................
  • Page 11 NANO-ULT5 SBC List of Tables Table 1-1: NANO-ULT5 Model Variations ..................3 Table 1-2: Technical Specifications ....................9 Table 3-1: Peripheral Interface Connectors ................17 Table 3-2: Rear Panel Connectors ....................17 Table 3-3: Audio Connector Pinouts ..................18 Table 3-4: Battery Connector Pinouts ..................20 Table 3-5: Digital I/O Connector Pinouts ..................
  • Page 12 NANO-ULT5 SBC Table 3-30: USB 3.1 Gen 2 Port Pinouts ..................51 Table 4-1: AT/ATX Mode Select Switch Settings ............... 60 Table 4-2: Backlight Mode Select Jumper Settings ..............62 Table 4-3: Flash Descriptor Security Override Jumper Settings ..........63 Table 4-4: LCD Voltage Selection Jumper Settings ..............
  • Page 13 NANO-ULT5 SBC List of BIOS Menus BIOS Menu 1: Main ........................78 BIOS Menu 2: Advanced ......................79 BIOS Menu 3: CPU Configuration ....................80 BIOS Menu 4: PCH-FW Configuration ..................82 BIOS Menu 5: Trusted Computing ....................83 BIOS Menu 6: ACPI Settings ....................... 84 BIOS Menu 7: RTC Wake Settings ....................

  • Page 15: Introduction
