  • Page 1 MSI-8000HD RF Remote Display Technical Manual May 15, 2018 PN 159007 Rev B...
  • Page 2 All information contained within this publication is, to the best of our knowledge, complete and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
  • Page 3: Table Of Contents

    Reset the Load Cell Calibration ............... . 20 Technical training seminars are available through Rice Lake Weighing Systems.
  • Page 4 8.0 Specifications ............... . . 40 Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost.
  • Page 5: Introduction

    2.4 GHz frequency. It is fully sealed for outdoor use in most ambient conditions and enhances the safety and usability of Rice Lake’s Dyna-Link and crane scale systems. Installed optional relays optimize work-flow and process control.
  • Page 6: Safety

    Do not operate or work on this equipment unless this manual has been read and all instructions are understood. Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake Weighing Systems dealer for replacement manuals.
  • Page 7: Front Panel Description

    Introduction Front Panel Description The MSI-8000HD front panel, keys and annunciators, are described in Table 1-1. Class III/IIIL n =10000 FUNCTION SETPOINTS PRINT POWER ZERO MSI-8000 Measurement Systems TARE International Figure 1-1. Front Panel 1.3.1 Key/Annunciator Functions Item Description Function 1 Key –...
  • Page 8: System Configurations

    MSI-8000HD RF Remote Display System Configurations The MSI-8000HD models and part numbers are listed below. Part No Description Notes Non RF Versions 154853 MSI-8000HD-1, Final Assy Remote Display Battery Common version, no RF 159381 MSI-8000HD-1, 18-72VDC Isolated, 2 Channel Hi-V forklifts 24VDC-72VDC...
  • Page 9: Operation

    Operation Operation This section covers the basic operation of the MSI-8000HD. Power Power the indicator On/Off by pressing POWER Zero Sets the zero reading of the scale/Dyna-Link to remove small deviations in zero when the unit is unloaded. See Section 2.3 zeroing (taring) a package, rigging or pallet weights.
  • Page 10: Installation

    The MSI-8000HD is often shipped pre-configured with a compatible sensor unit such as an Dyna-Link 2 or one of the MSI crane scales. If the MSI-8000HD is purchased separately, or is to be used with a different system, the RF transceivers will have to be paired.
  • Page 11: Mounting The Msi-8000Hd

    Mounting with Tilt Stand A tilt stand is shipped with the MSI-8000HD for mounting. It can be mounted on a desk, counter or table. It can also be mounted to a wall or panel and the MSI-8000HD can be rotated for easy viewing.
  • Page 12: Setup

    Print () – outputs a configured text string to the RS-232 port on the base of the Dyna-Link Section 4.2.7 on page Tare () – not used, MSI-8000HD has a dedicated tare key Scan () – displays connected scan channels in order Total Remote Devices () –...
  • Page 13: Function Keys

    , F1 and F2. • Function key setup is independent of the connected scale/Dyna-Link function keys. • are standard on the MSI-8000HD and do not need to be programmed. PRINT TARE • If a function key does not work, the connected Scale/Dyna-Link may not be set up to support the key.
  • Page 14: Total

    MSI-8000HD RF Remote Display 4.2.2 Total 1. Ensure the total mode has been programmed in the setup menu. If this has not been set up, the assigned to F-Key Total will not work. 2. Program an . See Section 4.2 on page...
  • Page 15: Hi-Res

    . The current auto off time displays. 4. Press to scroll through the available times. 5. Press when the desired time is displayed. displays. SLEEP 6. Press to exit setup and store the settings. ZERO © Rice Lake Weighing Systems ● All Rights Reserved...
  • Page 16: Setpoints

    The MSI-8000HD supports eight setpoints. Common uses of setpoints are for warnings or process control. It comes standard with two LED outputs for triggered setpoints. The MSI-8000HD has an audible output option that is triggered by Setpoint 1. Contact Rice Lake Weighing Systems for other setpoint output options.
  • Page 17: Output

    . The currently saved battery life displays. 4. Press to toggle between the choices. 5. With choice displayed, press to select. displays. Stand 6. Press to save and exit to weighing mode. ZERO © Rice Lake Weighing Systems ● All Rights Reserved...
  • Page 18: Standards

    5. With choice displayed, press to select. displays. Func1 6. Press to save and exit to weighing mode. ZERO Contact Rice Lake Weighing Systems for more information on the standards settings. Visit our website www.RiceLake.com...
  • Page 19: Remote Display Scale Setup

    The MSI-8000HD RF Remote Display can be used to operate several MSI crane scales (MSI-4260, MSI-3460 and MSI-7300). Some functions can also be set using the MSI-8000HD. The information in this section pertains to the setup of the scale being used with the remote.
  • Page 20: Total Mode

    MSI-8000HD RF Remote Display 4.8.2 Total Mode For the accumulation of multiple weighments, the Total function uses the displayed load, so gross and net readings can be added into the same total. There are four modes of totalizing, a manual and three auto modes.
  • Page 21: Calibration

    Note The MSI-8000HD Remote Display will need to be resealed after calibration is complete, to be in compliance with NTEP. Initial Calibration Initial calibration is used to setup units, capacity and resolution (d) required for the load cell or after a calibration reset.
  • Page 22: Routine Calibration

    MSI-8000HD RF Remote Display 6. With desired unit displayed, press to select. is displayed. 7. Press . The default capacity is displayed. 8. To enter a different capacity, press 9. Press to scroll through numbers and to save the selected numbers.
  • Page 23: C-Cal Calibration

    Cal value stamped on the serial number label. When a calibration is preformed with test weights, a new C-Cal is generated. The C-Cal number must be known prior to starting this procedure. Rice Lake prints this number on the serial number label. C- Cal reduces slightly the accuracy of the system and is intended for non-critical use only.
  • Page 24: Setup

    MSI-8000HD RF Remote Display Setup Setup is used to set the desired Industry Standard and Auto Zero Maintenance (AZM). 1. Press simultaneously. displays. ZERO 2. Press to scroll to SEtUP 3. Press displays. StAnd 4. Press , the current standard setting displays.
  • Page 25: Communications Setup

    • MSI-8000HD based RF systems are peer to peer. For multiple scale connections, the MSI-8000HD acts as the network coordinator. The MSI-8000HD uses three numbers to establish a piconet. A piconet is a network that is created using a wireless RF connection.
  • Page 26: Printer Setup

    The RS-232 communications port is capable of outputting load data. All of the RF linked weight device weight modes are available in user formatted form. The control mode program is what controls the MSI-8000HD to print and is described in Section 6.2.1.
  • Page 27: Standard Print Strings

    Combinations of the standard print strings can be entered in the string number entry screen. Example: To get a Net, Gross, Tare printout with a space between records, enter 2349. The ScaleCore Connect application can also be used for custom output strings, it can be downloaded from the Rice Lake website.
  • Page 28 MSI-8000HD RF Remote Display 6. Once all numbers are set, press to save the print mode. displays. Cntrl 7. Press . The current control mode displays. Press to scroll through the options. 9. When the desired control mode is displayed, press displays.
  • Page 29: Rf Setup

    14. Press to scroll through numbers and to save the selected numbers. Rice Lake Weighing Systems recommends at least a four digit for the Network ID, to ensure there are no conflicts with Note any other 802.15.4 networks. 15. When number is correct, press to store the number.
  • Page 30: Setup Multiple Sensor Network

    Setup Multiple Sensor Network The MSI-8000HD can monitor up to four load sensors. The sensors can be read individually, in pairs or summed. Dyna-Link 2 is shown for illustration purposes only. The Challenger 3 or Port-A-Weigh can also be used.
  • Page 31: Set The Total Number Of Load Cells

    6. When correct number of remote displays attached (1-4) is displayed, press . See Section 4.2.8. This number does not include the MSI-8000HD or any modems. displays.  7. Press . The load totaling setting displays. 8. Press to scroll through numbers and to save the selected numbers.
  • Page 32: Scanlist Id

    MSI-8000HD RF Remote Display Sensor summing disabled. A function key set to is unnecessary. ttl.rd 1. Program an to the function. See Section 4.2 on page 9. The current channel is displayed. F-key  2. Press is displayed briefly, then the summed total.
  • Page 33: Communications Port Hardware

    Communications Setup Communications Port Hardware The MSI-8000HD RF Remote Display RS-232 communication port is used for software updates, connecting to a remote display and for connecting to any RS-232 device. Connector: M12 industrial IP67 rated. An adapter cable (PN 150964) is required to connect the MSI-8000HD RF Remote Display to a computer.
  • Page 34: Relays

    Figure 6-6. DTE Configuration for Direct Connection to a DCE Printer Relays The MSI-8000HD can be equipped with up to two relays for process control or safety systems. Two independent relays are factory installed and are wired out to 4 pins on a M12 connector. The connecting cables are shown in the table below.
  • Page 35: Relay Options

    • AC/DC SSR 400 VPK, 0.5 A: 14628 AQZ404. 0.5 A Fuse 144583 (Use limited to 250 VRMS due to connector and Cordset limitations). One 1 Form B closed SSR NOTE: Requires a minor modification on the Relay board and can only be ordered by contacting Rice Lake Weighing Systems. See Figure 6.8.2 on page Table 6-11.
  • Page 36: Extended Relay Kit - Optional

    FCC Statement Contains FCC ID: MCQ-PS2CTH The MSI-8000HD complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation.
  • Page 37: 6.11 Antenna Options

    Communications Setup 6.11 Antenna Options To meet FCC licensing rules, use only antennas supplied or recommended by Rice Lake Weighing Systems. Note Antenna placement is critical to problem-free use of the system. • Ensure a relatively clear transmission path exists between the devices to be connected. Radio signals travel primarily by line of sight (LOS), obstructions between stations may degrade the system performance.
  • Page 38: 6.11.1 Standard Antenna

    Lake Weighing Systems for details. 6.11.5 Corner Reflector Antenna Corner reflector antennas are often the best choice for a wall mounted antenna. Rice Lake Weighing Systems offers a 14 dBi and a 9 dBi corner reflector. 14 dBi Corner Reflector 9 dBi Corner Reflector 6.11.6 Patch Antenna...
  • Page 39: Troubleshooting And Maintenance

    The load will not tare or total The system not stable the motion window; contact Rice Lake Weighing Systems if there is a problem getting the MSI-8000HD to zero, tare or total due to stability issues Set point is enabled and the trigger point...
  • Page 40: Error Codes

    Power up will be interrupted when the lift counter exceeds 16383 lifts or the overload counter exceeds 1023 overloads. Inspect the load train, then push any key to continue operation. This feature is only available on MSI-8000HD Software release 2.00 and above. Service counters are available on the scale/ Dyna-Link 2 front panel test function.
  • Page 41: Mechanical Dimensions

    Troubleshooting and Maintenance Mechanical Dimensions 8.98” 1.35” 1.63” Figure 7-1. MSI-8000HD Dimensions 9.50 8.02 6.16 9.13 3.25 11.06 Figure 7-2. MSI-8000HD Dimensions with Tilt Stand © Rice Lake Weighing Systems ● All Rights Reserved...
  • Page 42: Firmware Update

    2. Connect to the Dyna-Link serial port using the DCE cable. Connect the D9 connector to a PC or USB adapter. 3. Optional step: Test that there is a connection by typing {00FF01?}. If the connection is good the MSI-8000HD will respond with {000001r2;0;01E02;2011-07-08;11:05} or something similar.
  • Page 43: Reset The Remote Control

    Section 5.2 on page IMPORTANT Pressing will reset only the current load cell calibration settings. See Section 5.4 on page Note Press the to cancel reset and return to the previous menu. POWER © Rice Lake Weighing Systems ● All Rights Reserved...
  • Page 44: Specifications

    MSI-8000HD RF Remote Display Specifications Enclosure NEMA Type 4, IP68 milled anodized aluminum with o-ring gaskets Keypad On/Off, Zero (100%), Tare, Print, and two user-defined keys for the following functions: peak hold, high resolution, total, view total, net/gross, units switching Display 6-digit 1.0'' (25 mm) LCD...
  • Page 46 Specifications subject to change without notice. Rice Lake Weighing Systems is an ISO 9001 registered company. 230 W. Coleman St. • Rice Lake, WI 54868 • USA U.S. 800-472-6703 • Canada/Mexico 800-321-6703 • International 715-234-9171 • Europe +31 (0)26 472 1319...
