16.1 Changing Speed Step Settings: Status Editing

To Change the Speed Step Settings for a Decoder:
1. Select the loco address you want to status edit.
2. Press the Loco Key once to enter loco selec-
tion mode, the large numbers in the Loco
Info Area will begin to blink black and gray.
The soft keys will also change to give you
the options "MU", "Recall" and "MORE".
Press the C Soft Key labeled "MORE": This
3.
will bring up the additional loco selection
tasks of "Disptch" and "Stat.Edit" above the
A and B Soft Keys. Pressing the C Soft Key
labeled "MORE" will return you to "Mu"
and "Recall" soft key selections.
Press the B Soft Key labeled "Stat.Edit".
4.
5. The Status Edit Loco# menu will appear dis-
playing the available speed step settings.
6. Press the number on the keypad to select the corresponding speed step
setting. The menu will exit and you will see the corresponding speed selec-
tion in the Additional Loco Selection Info area.
7. Once the speed step setting you want to use is in the display, press the
Loco Key to complete the selection and speed step setting change. Once
this change is made, the DCS52 command station will send DCC com-
mands to the edited decoder in the speed step setting you entered.
17.0 Adding Throttles: LocoNet & Jump Ports
Sooner or later you will probably want to have one or more other people run
trains with you. This means you'll have to add more throttles to your DCS52.
You can add any LocoNet throttle to your DCS52 or you can use one or two
smooth DC power packs as jump throttles.

17.1 Adding LocoNet Throttles To Your DCS52

Any LocoNet throttle can be used with your DCS52. Simply plug the LocoNet
throttle into either LocoNet port on the back of your DCS52 or into any
LocoNet or Throttle Jack anywhere on your LocoNet system. If you want to
be able to plug in a throttle at a remote location, we recommend using a UP5
Universal Panel.
Your DCS52 can handle up to 20 LocoNet Throttles. If you need to run more
than 20 throttles, you can move up to a Digitrax Command Station with addi-
tional capacity. You can continue to use your DCS52 as a throttle and booster
with any command station on your Digitrax LocoNet system.
