10.1.1 Function 0 (F0) Headlights Forward and Reverse

Press the 0 key to toggle F0 between on and off. Each time the 0 key is pressed
while in function mode, Function 0, also called F0 will change from off to on
or vice-versa. On locos with reversing head lamps and back up lamps, the head
lamp or back up lamp in your loco will come on depending on the direction of
travel of the loco. Function 0 is most often used to turn on/off the head light/
back up light but can be set up for other functions as well (See your Decoder
Manual for more information). It can be used as two functions.
10.1.2 Functions 1,3, 4, 5, 6, 7, 8 & 9
Press the number key on the numeric keypad that corresponds with the function
number you want turn on/off. The function will toggle between on and off each
time you press the number key.

10.1.3 Function 2 (F2) Momentary Operation

Press the 2 key on the numeric keypad. The 2 key operates Function 2 and
is the preferred function for whistle or horn operation. This key is set up as a
"non-latching key" so that if a horn or whistle sound is installed in the loco, it
will sound for as long as the key is held down. This lets you vary the length of
time that the horn or whistle blows, just like the prototype.

10.2 Functions 10 through 28 (F10 - F28)

From the Home Operations Screen, press the A Soft Key labeled "Fn+00" to
cycle through the functions "Fn+10" and "Fn+20". When "Fn+10" is displayed
over the soft key the numeric keypad will control functions 10-19. If "Fn+20"
is displayed the keypad will control functions 20-28. Press the A Soft Key
again to return to "Fn+00" which will allow the keypad to control functions
0-9. In addition to watching the soft key data the full function number and sta-
tus will be displayed in the Function Bar area of the display.

10.3 Fn Info+

If you wish to view the status of all 29 functions you can use the "Fn Info+"
Trk USB
0 1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19
20 21 22 23 24 25 26 27 28
Local Throttle Active
sp 0 %
0003
F R
Fn+00 Active
© 2019 Digitrax, Inc.
soft key. From the Home Operations Screen, press
Ln
the C Soft Key labeled "Fn Info+" this will expand
the Function Bar area to show functions 0-28. To
collapse these press the C Soft Key labeled "Fn
Info-".
NOTE: The functions controlled by keypad
still correspond to the status of the A Soft Key,
"Fn+00", "Fn+10", and "Fn+20".
