Programming On The Mainline - Digitrax Zephyr Express DCS52 Manual

2. To enter the CV Programmer, press the Menu Key. Main Menu A will dis-
play giving you a list of menu options. Select 2- CV Programmer by press-
ing the 2 key on the keypad.
3. You will be presented with CV Program Menu A. From this menu use the
keypad to select the method of programming you wish to use by pressing
the corresponding number.
• 1-Po; Ops on Mainline
• 2-Pd; Direct on Prg Trk
• 3-Pg: Paged on Prg Trk
• 4-Ph: Physical on Prg Trk
Note: Direct programming is the Digitrax pref-
fered method
4. Once you have selected a programming
method, it will be listed above entries for
CV number and CV data. CV number is the
number of the CV you are changing. CV
data is the value you are programming to
the CV number.
5. To change the CV number you are editing
press the A Soft Key "CVNUM", then use
the keypad to enter the CV number you want to change.
6. Once you have the CV number selected press
the B Soft Key "CVDATA". The soft keys
will change to "WRITE", "READ", and
"BACK". Press the B Soft Key "READ"
to read the current value of the CV number
you have selected. Use the keypad to enter
the value you wish to program to the CV
number you have selected. Press the A Soft
Key "WRITE" to save the data entered. The
Scrolling Help Text line will read "Program
Task OK" when it has successfully pro-
grammed the value.
Press C Soft Key "BACK" to exit to the
7.
previous menu to select another CV to change if you wish. If you are done
editing CVs press C Soft Key "DONE" to return to normal operations.

11.4 Programming On The Mainline

Operations (OPS) Mode Programming lets you program CVs in DCC loco-
motives equipped with extended packet format decoders while they are on the
mainline. A typical use for OPS mode programming would be to change the
acceleration rate (CV03) or the deceleration rate (CV04) of your locomotives
to simulate the weight and braking capability of the train to compensate for
changing the number of cars or power units on a train.
© 2019 Digitrax, Inc.
Recall Session Loco List:
0- Last Menu
1- Po; Ops on Mainline
2- Pd; Direct on Prg Trk
3- Pg; Paged on Prg Trk
4- Ph; Physical on Prg
5-
6-
7-
8-
9-
CVNUM
CV Program Menu A:
2- Pd; Direct on Prg Trk
CV Number:
CV data:
CVNUM
26
26
Trk USB Ln
Trkk
CVDATA DONE
Trk USB Ln
0001
0001
CVDATA DONE
