Introduction

1.1

Features

• ATtiny1607-MNR Microcontroller
• One Yellow User LED
• One Mechanical User Switch
• On-Board Debugger
– Board identification in Atmel Studio/Microchip MPLAB
– One green power and status LED
– Programming and debugging
– Virtual COM port (CDC)
– Two logic analyzer channels (DGI GPIO)
• USB Powered
• Adjustable Target Voltage
– MIC5353 LDO regulator controlled by the on-board debugger
– 1.8-5.1V output voltage (limited by USB input voltage)
– 500 mA maximum output current (limited by ambient temperature and output voltage)
1.2

Kit Overview

The Microchip ATtiny1607 Curiosity Nano evaluation kit is a hardware platform to evaluate the
ATtiny1607 microcontroller.
Figure 1-1. ATtiny1607 Curiosity Nano Evaluation Kit Overview
©
