function is one of the following codes:
l
function
0
1
2
"string" is formatted as an IP address and entered as a string
l
For example:
IPCTL(0,"192.168.0.10")
For more details on the IPCTL command, see the SmartMotor™ Developer's Guide. For details
on the Ethernet and USB ports, see the Class 6 SmartMotor™ Installation & Startup Guide.

Supported/Not-Supported Functionality

Supported Functionality

A small set of functions are supported for access to these basic SmartMotor operations:
Report commands: RPA, RSP, etc.
l
Report commands are shown in the SmartMotor Developer's Guide. They can be
identified by looking at the command lists (near the end of the guide) for commands
that begin with a superscript "R" character, for example:
Commands that begin with an "R" character that is not superscript are not report
commands, for example: RANDOM=, RESUME, RETURN, RETURNI, RUN, RUN?.
NOTE: Also, refer to the Not-Supported Functionality section.
For more details, refer to Example with a String Response on page 24 and Example with
a Numeric Response on page 25.
Assign a variable: a=400
l
For more details, refer to Example of Assigning a Variable on page 26.
Moog Animatics Class 6 SmartMotor™ Ethernet Serial Encapsulation Guide, Rev. B

Supported/Not-Supported Functionality

Description
Set IP address
Set subnet mask
Set gateway
'Set the IP address to 192.168.0.10
Page 19 of 32
R R R
PA, SP, PC etc.
