Specifications; Figure 1-2. Printed Circuit Model Number Location - Microwave Data Systems MDS 4310 Installation, Operation & Field Maintenance

Figure 1-2. Printed Circuit Model Number Location

SPECIFICATIONS: MDS 4310 DATA TRANSCEIVER (2314 MAIN PC BOARD)
General
Frequency Range:
Operating Bands—
any one of eight:
Frequency Programming:
TX/RX Spacing:
Primary Power—
Model 4310 Transceiver
Voltage:
TX Supply Current:
RX Supply Current:
Standby Current (Radio Inhibited) :
Connector:
Fuse:
Reverse Polarity Protection:
Continued on next page.
MDS 05-2415A01, Rev. A
PRINTED CIRCUIT
BOARD MODEL
LABEL
2 4
1 2
1 3
3 4
1
2
3
350–512 MHz (Nominal)
350–370 MHz, 370–390 MHz, 390–410 MHz,
406–430 MHz, 430–450 MHz, 450–470 MHz,
470–490 MHz, and 490–512 MHz
Programmable in 6.25 kHz increments to any
channel pair in radio operating sub-band.
0 (Simplex), 5 MHz, 10 MHz standard; others
are possible, consult with factory.
13.8 Vdc Nominal
(10.5–16.5 Vdc Operating Range)
2.0 A typical, 2.5 A Maximum, at 13.8 Vdc
Varies with power output adjustment
65 mA typical, without options installed or
LED indicators turned OFF
14 mA maximum
Integral part of power cable assembly
(Six foot/1.8 meter cable assembly included)
3.0 A, 3AG, FB (Fast Blow);
Holder part of cable assembly
Diode across primary power input with
internal 4 A plug-in fail-safe fuse.
GENERAL 1-5
