9.0 TECHNICAL REFERENCE

The following section contains material that is not essential to using the
radio, but may prove helpful in diagnosing performance problems or in
gaining a better understanding of the unit's operation.

9.1 Technical Specifications

GENERAL
Temperature Range:
Humidity:
Primary Power:
External Power Supply Options:
Supply Current (typical):
Transmit:
Receive:
Doze Mode:
Size (Excluding mtg. hardware):
Mounting w/Optional Hardware:
Weight:
Case:
Shock and Vibration:
APPROVALS/HOMOLOGATION (PLANNED)
UNIT & NETWORK MANAGEMENT
MDS iNet 900 Installation Guide
DRAFT 6—8/29/01
–30°C to +70°C (–22° F to 158° F)
95% at +40°C (104° F); non-condensing
10.5–30 Vdc(13.8 Vdc Nominal)
48 Vdc; 110–120/210–220 Vac
(@ 1 Watt RF Output)
500 mA @ 13.8 Vdc
< 125 mA @ 13.8 Vdc
< 30 mA @ 13.8 Vdc
1.5" x 6" x 4" (H x W x D)
3.8 x 15.2 x 10.2 cm
• Flat surface mounting brackets
• DIN rail
• 19" rack (1U high)
0.9 kg / 2 lb
Cast Aluminum
MIL STD 202F, 810E, 202D
• FCC Part 15.247
• Industry Canada RSS-210 and RSS-139
• UL/FM Class 1, Div. 2; Groups A, B, C and D
hazardous locations
• UL Listed
• CE Mark
• Contact MDS for information on availability and
governmental approvals in other countries
• HTTP (Embedded Web server)
• SNMPv1, MIB II, Enterprise MIB
• Text-based menu on COM1 serial port
• Telnet
