PROGRAMMING AND TEST COMMANDS
Table 3-2 contains a list of all HHT programming and diagnostics commands.
Some command strings in Table 3-2 include an underscore "_"
symbol to denote a
reminder only, and should not be entered.
Table 3-2. Programming and Test Commands—Part 1 of 3
OPEN ... OPEN the Diagnostics Channel
STAT .... Display status of hardware profile
Displayed below are the functions of each display character and its meaning.
1
Keyed Status ................ U – Unkeyed
2
Diagnostic Mode .......... S – Standard (Mode 1)
3
Diagnostic Hardware ... A – Installed, LBC Valid
OWM .... Display Owner's Message
HREV ... Transceiver hardware revision level
MD........ Transceiver manufacture date
MO ....... Model number of radio
CTS ...... Displays CTS delay in ms
FRQ ..... Frequencies currently set in MHz
LBC ...... Display Loopback code (4 digits)
SCD
Display Soft Carrier Dekey in ms
FPWR .. Forward RF power*
LV ........ PLL VCO lock voltage
RPWR .. Reverse RF power*
RSSI .... Received Signal Strength Indicator*
* Information is updated every second
MDS 05-2415A01, Rev. A
NOTE
key press. The underscore is a visual
SPACE
DIAGNOSTICS CHANNEL
DISPLAY COMMANDS
HARDWARE STATUS
K – Keyed
T – Timed Out
A – Advanced (Mode 2)
R – Remote Maint. (Mode 3)
B – Installed, LBC Invalid
C – Uninstalled, LBC Valid
D – Uninstalled, LBC Invalid
OWNER'S INFORMATION
RADIO INFORMATION
OPERATING PARAMETERS
DIAGNOSTIC INFORMATION
PROGRAMMING AND DIAGNOSTICS
CLOS ... CLOSE the Diagnostics Channel
4
Diagnostic Module ....... I – Installed
U – Uninstalled5
Base/Remote .............. B – Base (High Side LO)
R – Remote (Low Side LO)
6
IF/LO Arrangement ..... 0 – 45 MHz/Low
7
RSSI Cal. Status .......... Y – Calibrated
N – Uncalibrated
8
RF Power Status.......... Y – Calibrated
N – Uncalibrated
OWN .... Display Owner's Name
SER...... Serial number of radio
SREV ... Transceiver firmware revision level
PTT ...... Display Push-to-Talk delay in ms
STE ...... Display Squelch Tail Eliminator (STE)
Status— ON or OFF (Normally OFF if VOX
function is used.)
TOT ...... Display Time-out Timer length (sec)
SV........ Supply voltage to radio*
TEMP... Internal temperature in degrees Celsius*
VR ........ Regulator voltage output ≈8 Vdc*
VSWR .. VSWR at ANTENNA connector*
3-11
