8. Install the covers and check the transceiver for proper operation.

6.3 TECHNICAL SPECIFICATIONS

GENERAL
Temperature Range:
Humidity:
Primary Power:
External Power Supply Options:
Supply Current (typical):
Transmit:
Receive:
MTBF:
Size (Excluding mtg. hardware):
Mounting w/Optional Hardware:
Weight:
Case:
Boot Time:
Time Required to Associate
with Access Point:
APPROVALS/HOMOLOGATION
MDS iNET 900 Series User's Guide
Figure 6-4.
Internal Fuse and Holder
Assembly Location
Invisible place holder
–30° C to +60° C (–22° F to 140° F)
95% at +40° C (104° F); non-condensing
10–30 Vdc (13.8 Vdc Nominal)
110–120/210–220 Vac
(9 Watts Maximum @ 1 Watt RF Output)
8 watts (10.5-24 Vdc)
9 watts (24.5-30 Vdc)
2.8 watts (10.5-24 Vdc)
3.5 watts (24.5-30 Vdc)
35 Years (Telcordia Method 1, Case 3)
1.4" x 6.75" x 4.5" (H x W x D)
3.56 x 17.15 x 11.43 cm
• Flat surface mounting brackets
• 19" rack (1U high)
908 g / 2 lb
Cast Aluminum
≈ 30 sec
≈ 20 sec
• FCC Part 15.247
E5MDS-NH900
• Industry Canada RSS-210 and RSS-139
CAN 3738A 12098
• UL/CSA Class 1, Div. 2; Groups A, B, C and D
hazardous locations
• Contact factory for information on availability and
governmental approvals in other countries
MDS 05-2806A01, Rev. E.1
