JessEm Mite-R-Excel II Owner's Manual page 21

Item No. Part No.
1 F0416
2 S0062-19
3 S0065-7
4 F0411
5 S0061-13
6 E0300-1
7 E0296-2
8 S0065-8
9 F0407
10 E0205-8
11 M0381
12 E0092-3
13 E0297-1
14 S0075-1
15 F0415
16 S0053-35
17 F0414
18 F0413
19 F0348
20 E0206-5
21 S0053-36
22 E0130-2
23 E0246-4
24 S0061-15
25 S0075-2
26 E0294-1
27 M0375
28 E0295-2
29 F0355
30 E0295-1
31 F0418
32 M0376
33 E0293-1
34 M0382
35 S0061-15
36 E0274-2
37 F0417
38 S0061-13
39 F0394
40 S0061-17
41 S0054-7
42 S0061-16
43 M0379
44 E0301-1
45 S0053-33
46 E0296-1
47 S0065-9
48 M0377
49 M0136
50 E0070-2
51 S0062-18
52 S0064-10
53 F0408
54 F0409
55 S0076-1
56 S0066-1
57 F0028
58 F0430
59 M0027
60 M0045
61 F0500
62 F0429
63 S0079-1
64 S0061-18
MITE-R-EXCEL II™ PARTS LIST
Part Description
#008 Buna-N O-Ring
Guide Bar Snugger
Snugger Mounting Screw
#8-32 X 1/8" Cup Point Set Screw
Indexing Pin Knob
Gauge Body
LH Fence Mount Bracket
#10 Heavy Washer
#10-32 X 7/8" Socket Head Screw
Handle
Clamping Handle
Fence Stop Mount
Flip Stop Lower
Fence Stop Stud
1/4-20 Nylon-Insert Locknut
1/4" Washer
1/4-20 X 1/2" Button Head Cap Screw
1/4-20 X 3/4" Button Head Cap Screw
1/4" ID X 5/8" OD Washer
Flip Stop Upper
Extension Stop Screw
Fence Extension Stop
Fence Extension Insert
Fence Extension T-Bolt
Fence Extension Insert Locking Pin
Fence Extension
Fence Extension Scale
Fence Extension Scale Bar
#8-32 X 3/16" Flat Point Set Screw
Scale Bar
#10-32 X 1/4" Socket Head Cap Screw
Fence Extrusion Scale
Fence Extrusion
UHMW Wear Strip
Flip Stop T-Bolt (Short T-bolt)
Fence Locating Nut
#10-32 X 3/16" Flat Point Set Screw
Fence Locating Pin
1/4-28 X 5/16" Thread Locking Flat Point Set Screw
Fence Locating Pin Knob
3/8" ID X 1" OD Washer
Gauge Pivot
3/8" ID Oil-Embedded Flanged Sleeve Bearing
Fence Mount
Fence Knob
RH Fence Mount Bracket
Indexing Pin
Compression Spring
3/8" ID Oil Embedded Sleeve Bearing
Indexing Block
Indexing Pin Lock Bushing
Gauge Bar Retaining Washer
#10-32 X 5/16" Flat Head Screw
1/4-20 X 1/2" Low Head Cap Screw
#10-32 X 5/16" Low Head Cap Screw
Guide Bar
1/4-20 Square Nut
1/4-20 X 1-1/8" Phillips Flat Head Screw
5/32" Hex Key
1/8" Hex Key
3/32" Hex Key
5/64" Hex Key
Allen Key Extension
Fence Clamping T-Bolt (Long T-Bolt)
21
Qty
4
3
3
1
1
1
1
8
8
1
2
1
1
1
1
1
1
1
4
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
2
1
2
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
2
1
2
2
1
1
1
1
1
2
