Using the Mite-R-Excel II ™
After making any adjustments to the Mite-R-Excel II™, ensure the fence is clear of the
table saw blade and the clamping handle is tight before making any cuts.
Engaging and Disengaging the Indexing Pin Knob
DISENGAGED INDEXING PIN KNOB
50
51
5
ENGAGED INDEXING PIN KNOB
47
50
51
5
14
Disengaged indexing pin knob. (Pulled out and
turned). Use in this position for adjusting
increments and all non predetermined detent
positions on the gauge.
Figure 16
Use in this position when using predetermined
detents of 0°, 15°, 22.5°, 30° and 45°
Figure 17
