User Manual
Model #02302, #02303, #02304
Thank you for choosing this product from
JessEm Tool Company. We appreciate your
support and hope that our product serves you
well. This product is designed to provide
many years of reliable service provided it is
used as intended and taken care of.
This user manual will assist you in assembly
and general operation of this product. It is
not our intent to teach you about
woodworking. It is assumed that you are an
experienced woodworker with the basic skills
and experience necessary to use this product
safely. If after reading the following
instructions, if you are unsure or
uncomfortable about safely using this
product we urge you to seek additional
information through widely available
woodworking books or classes.
Suggested Router Bit Speeds
Bit Diameter
1" (25mm)
1-1/4" - 2" (30-50mm)
2-1/4" - 2-1/2" (55-65mm) 16,000 RPM
3" - 3-1/2" (75-90mm)
Lift FX
Max. Speed
24,000 RPM
18,000 RPM
12,000 RPM
124 Big Bay Point Road
Barrie, Ontario, L4N 9B4
Canada
866-272-7492 Toll Free
705-726-6145 Local Phone
705-726-6055 Fax
Email: jessem@jessem.com
Website: www.jessem.com
IMPORTANT!
Read and understand the contents of
this manual before assembly or
operation of this product.
As part of our Continuous Product
Improvement Policy, JessEm products are
always advancing in design and function.
Therefore there may be differences between
what is shown in our catalogs, website or at
retail display and what is sold at time of
purchase. We reserve the right to make
positive changes to our products at our
discretion.
Model #02302 -
Fits Porter Cable 690, 890 series,
Bosch 1617, 1618 series,
DeWalt 610, 616, 618 series
Model #02303 -
Fits Makita 1101 series
Model #02304 -
Fits Milwaukee 5615, 5616, 5619 series
27956
RTD10000134AA
