Safety Marking - probst VPH-150 Operating Instructions Manual

Safety
2.4

Safety Marking

PROHIBITION SIGN
Symbol Meaning
WARNING SIGN
Symbol Meaning
Danger of squeezing the hands.
REGULATORY SIGN
Symbol Meaning
Each operator must have read and understood the operating
instructions (and all safety instructions).
Loads have to be sucked in centered. With a suitable device (height
adjustable stop) loads can also be sucked in eccentrically.
Safety chains has to fit tightly to the load.
Safety chains should never hang loosely under the load!
OPERATING INFORMATIONS
Symbol Meaning
Maximum working load limit of the suction plate (VPH-100)
Maximum working load limit of the suction plate (VPH-150)
Label with device title
5271.0008
It is not allowed to stand under hanging loads. Danger to life!
Working with this device is only permitted in proximity to the
ground.
The sucked load must never be lifted more than 1.8 m
(measured from the top edge of the load to the ground).
Swinging the device over persons is prohibited.
V1
6 / 24
