- Page 1 GARAGE JACK CTJ3000G MODEL NO: PART NO: 7623030 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC1217...
-
Page 2: Specifications
INTRODUCTION Thank you for purchasing this CLARKE Garage Jack. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Safety Precautions
9. Do not try to lift more then the rated load for the jack. 10. Do not use the jack if an oil leak is apparent. Consult your Clarke dealer. 11. Consult the vehicle handbook to determine the correct lifting points. -
Page 4: Unpacking And Assembly
UNPACKING AND ASSEMBLY 1. Connect the two halves of the Operating Handle and secure with a nut and bolt. 2. Remove the packing wedge shown in fig. 2. 3. Remove the locating screw from the rear of the handle housing, shown in Fig 3 and insert the handle into the housing, ensuring the square drive on the end of the... - Page 5 3. Turn the control valve clockwise raise the jack to its full height. Pump the handle again several full strokes. 4. Test the jack and if efficiency is still low, repeat the above procedure with the oil filler plug loosened. Check the oil level as described under Maintenance.
-
Page 6: Operation
OPERATION Before use, inspect the jack for oil leaks or any other sign of damage. Should any be apparent, have the jack repaired by a qualified technician. WARNING: NEVER WORK ON THE VEHICLE WHEN SUPPORTED ONLY BY A JACK. THIS IS HIGHLY DANGEROUS. THE VEHICLE MUST BE SUPPORTED ON AXLE STANDS OR SUITABLE SUPPORTS, BENEATH THE CORRECT JACKING/ SUPPORT POINTS. -
Page 7: Maintenance
2. Store in a dry location. with the ram fully retracted. 3. In the event of damage or broken components, replacements are available from Clarke Parts & Service. ENVIRONMENTAL PROTECTION One of the most damaging sources of environmental pollution is oil products. -
Page 8: Troubleshooting
Air in the hydraulic Purge the system as on page 5 system Jack will not Return spring may Return to your Clarke dealer for lower completely be faulty. repair If any of these remedies fail to restore your jack, consult your Clarke dealer. -
Page 9: Declaration Of Conformity
DECLARATION OF CONFORMITY... -
Page 10: Component Parts - General Assembly
COMPONENT PARTS - GENERAL ASSEMBLY... - Page 11 COMPONENT PARTS - GENERAL ASSEMBLY Description No Description Circlip 20 mm Flat Gear Washer 20 mm Washer Front Wheel Gear Mounting Bolt Frame Handle Set Screw Support Pivot Bolt Torsion Spring Saddle Screw M6 x 35 Lift Arm Pivot Shaft Washer 8 mm Lift Arm Split Pin 2.5 x 12...
