- Page 1 3.5T GARAGE JACK CTJ3500LPQLPRO MODEL NO: PART NO: 7623251 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0324...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE Garage Jack. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
- Page 3 6. DO NOT make any modifications to this jack or adjust any valves. 7. DO NOT use the jack if an oil leak is apparent. Consult your CLARKE dealer. 8. DO NOT use to lift people and ensure that no-one is in the vehicle during lifting.
- Page 4 UNPACKING AND ASSEMBLY 1. Remove the transit retaining clip by springing it away from the yoke and tie rod. 2. Loosen the bolt in the yoke until the lower handle can be inserted fully into the handle socket. • The lower handle has a groove which will engage with the bolt once it is re-tightened.
- Page 5 OPERATION This jack incorporates a twin piston pump with a ‘quick lift’ facility to provide rapid raising of the unladen jack. When the jack encounters a load (the vehicle), its distance raised per stroke reduces to provide gradual lifting Before use, inspect the jack for oil leaks or any other sign of damage. Should any be apparent, have the jack repaired by a qualified technician.
- Page 6 • Oil can be topped up using Clarke Hydraulic Oil (p/n 3050830 1 litre). 4. Purge any air from the system and replace the filler plug and cover plate. 5. Dispose of any old/spilled oil appropriately and wipe up any spillage.
- Page 7 Air in the hydraulic Purge the system as on page 4 system Jack will not Return spring may Return to your Clarke dealer for lower completely be faulty. repair If any of these remedies fail to restore your jack, consult your Clarke dealer.
- Page 8 COMPONENT PARTS - RAM ASSEMBLY...
- Page 9 COMPONENT PARTS - RAM ASSEMBLY Description No Description Plug Screw O-Ring Sealing Ring Spring Plug Screw Spring Base Spring Steel Ball Spring Base Large Plunger Ball Split Washer Base Plate O-Ring Filter Oil Tube Spring Base Copper Washer Spring Barrel O-Ring Spring Back-Up Ring...
- Page 10 COMPONENT PARTS - GENERAL ASSEMBLY...
- Page 11 COMPONENT PARTS - GENERAL ASSEMBLY Description No Description Front wheel Piston roller shaft Washer 20 Piston roller Circlip Handle socket Rear wheel Gasket 12 Lifting arm hinge pin Hydraulic pump assembly Circlip Cover plate Lock washer Spring Bolt M10 x 25 Spacer Washer 5 -flat Pin 4 x 50...
- Page 12 DECLARATION OF CONFORMITY - UKCA...
- Page 13 DECLARATION OF CONFORMITY - CE...
- Page 14 GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt which will be required as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended.
