H3C S3100-8C-Sl Quick Start Manual page 25

Quick Start (For Japan)
H3C S3100 Series Ethernet Switches
Table 1-13 ONU module support of the S3100 series
Switch model
S3100-8C-SI
S3100-16C-SI
S3100-26C-SI
S3100-8C-EPON
-EI
S3100-16C-EPO
N-EI
S3100-26C-EPO
N-EI
All models of ONU modules look alike. Figure 1-1 and Figure 1-2
depict the LS6M2PU1SB.
Figure 1-1 Appearance of the LS6M2PU1SB
Number Required
of ONU
modules optional
1 Optional
1 Optional
1 Optional
1 Required
1 Required
1 required
2
1 optional
1-18
Chapter 1 Product Overview
ONU module
or
1000Base-PX10
(LS6M1PU1SA)
1000Base-PX20
(LS6M1PU1SB)
1000Base-PX20
(LS6M2PU1SB)
model
