7-2. CHASSIS SECTION

56
57
58
Ref. No. Part No. Description
51 3-237-072-01 SCREW (MD), STEP
52 3-238-127-01 SPACER (HOLDER)
53 X-3381-652-1 CHASSIS (5192) ASSY, SET
54 3-237-075-01 SPRING (POP UP-L), TORSION
55 3-237-083-01 SPRING (POP UP-R), TORSION
56 3-239-791-01 SHEET (FULCRUM PLATE LA)
56
51
51
52
53
54
55
57
60
59
Ref. No.
Remark
57
58
59
60
61
62
MT-MZN707-177
62
main board section
61
Part No. Description
3-318-382-91 SCREW (1.7X2.5), TAPPING
3-237-080-01 SLIDER, OPEN
3-237-082-01 SPRING (LOCK), TENSION
3-237-081-01 SPRING (LIMITTER), COMPRESSION
3-335-797-01 SCREW (M1.4X2), TOOTHED LOCK
3-239-800-01 SHEET (FULCRUM PLATE RA)
Remark
