Ref. No. Part No. Description
< RESISTOR >
R101 1-218-969-11 RES-CHIP
R102 1-208-707-11 METAL CHIP
R103 1-218-973-11 RES-CHIP
R104 1-218-961-11 RES-CHIP
R104 1-218-965-11 RES-CHIP
R104 1-218-969-11 RES-CHIP
R105 1-218-961-11 RES-CHIP
R106 1-208-635-11 RES-CHIP
R107 1-218-965-11 RES-CHIP
R111 1-208-715-11 METAL CHIP
R112 1-208-927-11 METAL CHIP
R118 1-208-715-11 METAL CHIP
R201 1-218-969-11 RES-CHIP
R202 1-208-707-11 METAL CHIP
R203 1-218-973-11 RES-CHIP
R204 1-218-961-11 RES-CHIP
R204 1-218-965-11 RES-CHIP
R204 1-218-969-11 RES-CHIP
R205 1-218-961-11 RES-CHIP
R206 1-208-635-11 RES-CHIP
R207 1-218-965-11 RES-CHIP
R211 1-208-715-11 METAL CHIP
R212 1-208-927-11 METAL CHIP
R218 1-208-715-11 METAL CHIP
R302 1-218-953-11 RES-CHIP
R303 1-218-937-11 RES-CHIP
R304 1-218-953-11 RES-CHIP
R305 1-218-953-11 RES-CHIP
R306 1-218-969-11 RES-CHIP
R307 1-218-941-11 RES-CHIP
R308 1-218-990-11 SHORT
R309 1-218-981-11 RES-CHIP
R310 1-218-990-11 SHORT
R311 1-218-989-11 RES-CHIP
R315 1-218-965-11 RES-CHIP
R316 1-218-977-11 RES-CHIP
R317 1-218-941-11 RES-CHIP
R318 1-218-953-11 RES-CHIP
R319 1-218-953-11 RES-CHIP
R320 1-218-965-11 RES-CHIP
R501 1-218-973-11 RES-CHIP
R502 1-218-981-11 RES-CHIP
R503 1-218-985-11 RES-CHIP
R505 1-208-707-11 METAL CHIP
R507 1-218-953-11 RES-CHIP
R517 1-208-683-11 METAL CHIP
R519 1-218-977-11 RES-CHIP
R521 1-218-446-11 METAL CHIP
R522 1-218-446-11 METAL CHIP
R551 1-218-965-11 RES-CHIP
R552 1-218-965-11 RES-CHIP
Remark Ref. No.
22K 5% 1/16W
10K 0.5% 1/16W
47K 5% 1/16W
4.7K 5% 1/16W
(FR)
10K 5% 1/16W
(EXCEPT US, FR)
22K 5% 1/16W
(US)
4.7K 5% 1/16W
10 5% 1/16W
10K 5% 1/16W
22K 0.5% 1/16W
47K 0.5% 1/16W
22K 0.5% 1/16W
22K 5% 1/16W
10K 0.5% 1/16W
47K 5% 1/16W
4.7K 5% 1/16W
(FR)
10K 5% 1/16W
(EXCEPT US, FR)
22K 5% 1/16W
(US)
4.7K 5% 1/16W
10 5% 1/16W
10K 5% 1/16W
22K 0.5% 1/16W
47K 0.5% 1/16W
22K 0.5% 1/16W
1K 5% 1/16W
47 5% 1/16W
1K 5% 1/16W
1K 5% 1/16W
22K 5% 1/16W
100 5% 1/16W
0
220K 5% 1/16W
0
1M 5% 1/16W
10K 5% 1/16W
100K 5% 1/16W
100 5% 1/16W
1K 5% 1/16W
1K 5% 1/16W
10K 5% 1/16W
47K 5% 1/16W
220K 5% 1/16W
470K 5% 1/16W
10K 0.5% 1/16W
1K 5% 1/16W
1K 0.5% 1/16W
100K 5% 1/16W
1 5% 1/10W
1 5% 1/10W
10K 5% 1/16W
10K 5% 1/16W
Part No. Description
R553 1-218-965-11 RES-CHIP
R560 1-218-957-11 RES-CHIP
R561 1-218-957-11 RES-CHIP
R562 1-218-957-11 RES-CHIP
R601 1-218-989-11 RES-CHIP
R602 1-218-981-11 RES-CHIP
R603 1-218-977-11 RES-CHIP
R604 1-218-446-11 METAL CHIP
R605 1-218-446-11 METAL CHIP
R606 1-218-949-11 RES-CHIP
R607 1-218-945-11 RES-CHIP
R608 1-218-981-11 RES-CHIP
R609 1-219-724-11 METAL CHIP
R610 1-218-969-11 RES-CHIP
R612 1-218-985-11 RES-CHIP
R613 1-218-957-11 RES-CHIP
R614 1-218-965-11 RES-CHIP
R615 1-218-957-11 RES-CHIP
R616 1-218-953-11 RES-CHIP
R620 1-218-965-11 RES-CHIP
R621 1-218-965-11 RES-CHIP
R622 1-218-977-11 RES-CHIP
R623 1-218-977-11 RES-CHIP
R624 1-216-797-11 METAL CHIP
R625 1-218-977-11 RES-CHIP
R626 1-216-789-11 METAL CHIP
R701 1-218-953-11 RES-CHIP
R702 1-218-985-11 RES-CHIP
R703 1-218-985-11 RES-CHIP
R704 1-218-990-11 SHORT
R705 1-218-957-11 RES-CHIP
R706 1-218-977-11 RES-CHIP
R707 1-218-961-11 RES-CHIP
R708 1-218-985-11 RES-CHIP
R709 1-218-941-11 RES-CHIP
R710 1-218-957-11 RES-CHIP
R711 1-216-864-11 METAL CHIP
R712 1-218-961-11 RES-CHIP
R714 1-218-990-11 SHORT
R715 1-218-973-11 RES-CHIP
R801 1-218-981-11 RES-CHIP
R802 1-208-903-11 METAL CHIP
R803 1-208-927-11 METAL CHIP
R804 1-218-957-11 RES-CHIP
R805 1-218-957-11 RES-CHIP
R806 1-218-949-11 RES-CHIP
R807 1-208-635-11 RES-CHIP
R808 1-218-965-11 RES-CHIP
R809 1-218-977-11 RES-CHIP
R810 1-218-977-11 RES-CHIP
R814 1-208-635-11 RES-CHIP
R815 1-218-990-11 SHORT
R816 1-218-990-11 SHORT
R817 1-218-977-11 RES-CHIP
R821 1-218-981-11 RES-CHIP
R822 1-218-953-11 RES-CHIP
R823 1-218-945-11 RES-CHIP
R824 1-218-957-11 RES-CHIP
MZ-N707
MAIN
Remark
10K 5% 1/16W
2.2K 5% 1/16W
2.2K 5% 1/16W
2.2K 5% 1/16W
1M 5% 1/16W
220K 5% 1/16W
100K 5% 1/16W
1 5% 1/10W
1 5% 1/10W
470 5% 1/16W
220 5% 1/16W
220K 5% 1/16W
1 1% 1/4W
22K 5% 1/16W
470K 5% 1/16W
2.2K 5% 1/16W
10K 5% 1/16W
2.2K 5% 1/16W
1K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
100K 5% 1/16W
100K 5% 1/16W
10 5% 1/16W
100K 5% 1/16W
2.2 5% 1/16W
1K 5% 1/16W
470K 5% 1/16W
470K 5% 1/16W
0
2.2K 5% 1/16W
100K 5% 1/16W
4.7K 5% 1/16W
470K 5% 1/16W
100 5% 1/16W
2.2K 5% 1/16W
0 5% 1/16W
4.7K 5% 1/16W
0
47K 5% 1/16W
220K 5% 1/16W
4.7K 0.5% 1/16W
47K 0.5% 1/16W
2.2K 5% 1/16W
2.2K 5% 1/16W
470 5% 1/16W
10 5% 1/16W
10K 5% 1/16W
100K 5% 1/16W
100K 5% 1/16W
10 5% 1/16W
0
0
100K 5% 1/16W
220K 5% 1/16W
1K 5% 1/16W
220 5% 1/16W
2.2K 5% 1/16W
63
