- Page 1 Operating Manual Ultra Elite Full Face Mask – Positive Pressure Order No.: 10110550/02 MSAsafety.com...
- Page 2 MSA Europe GmbH Schlüsselstrasse 12 8645 Rapperswil-Jona Switzerland info.ch@MSAsafety.com www.MSAsafety.com © MSA 2018 All rights reserved...
-
Page 3: Table Of Contents
Contents Safety Regulations ..........4 Correct Use. -
Page 4: Safety Regulations
MSA or authorized persons. Liability Information MSA accepts no liability in cases where the product has been used inappropriately or not as intended. The selection and use of the product are the exclusive responsibility of the individual operator. -
Page 5: Description
Description Description The face blank is made of a special soft rubber compound and assures a snug, comfortable fit and a tight seal. The face blank is also available in yellow silicone. Some versions of the mask are also avail- able in small size. -
Page 6: Mask Versions
Description Mask Versions Standard Thread Connector M45 x 3 Ultra Elite-PF • Standard version Ultra Elite-PF small • as standard version, small size • as standard version, face blank, inner mask and harness made Ultra Elite-PF-Si from silicone Ultra Elite-PF-EZ •... -
Page 7: Marking/Certification
Description Marking/Certification Marking The mask is marked on the outer face blank as shown in Fig. 2: Fig. 2 Marking of mask body Mask Version Part Number Marking [date code, serial number] CE-marking with notified body number [DEKRA EXAM, Zertifizierungsstelle Dinnendahlstr. 9, 44809 Bochum] X: ATEX classification A, B or C according to the Lens typ. -
Page 8: Use
The mask is either carried using the harness in front of the chest or in the mask container. In order to protect the inside of the mask from dirt, the harness hook is engaged in the front buckle when the mask is held in front of the chest. WARNING! Ensure that the top of the mask seal only... -
Page 9: Leak Check
Leak Check In order to check the mask-to-face tightness a leak test must be performed before each use. Seal the mask connector or the inlet opening side of an attached filter with the ball of your hand. Test tightness by inhaling and exhaling. Whilst doing so: when inhaling there must be negative pressure, no inflowing air should be noticeable. -
Page 10: Cleaning, Disinfection
Cleaning, Disinfection Cleaning, Disinfection The cleaning and disinfection of the masks is performed in accordance with the cleaning intervals chapter 5.2. There are three possible kinds of cleaning: • Using a washing machine • disk washing type (Meiko) • tumbling type (Miele) •... -
Page 11: Cleaning By Hand
Cleaning, Disinfection Cleaning by Hand Remove inhalation and exhalation valve discs. Unbutton the nose cup. Unscrew the speaking diaphragm with the special tool. Clean mask using lukewarm water and mild cleaning agent EW 80 and thoroughly rinse in running water. Disinfect the mask after cleaning. -
Page 12: Maintenance
Always use original parts from MSA. Repairs and maintenance must be carried out only by authorised service centres or by MSA. Changes to devices or components are not permitted and will result in loss of approval. -
Page 13: Maintenance Of The Exhalation Valve
Perform a tightness test [ chapter 5.5]. Tightness Test of the Mask The testing of the masks for tightness is performed using an applicable MSA test device in accordance with the relevant operating manual. Fit mask tight onto the test instrument. -
Page 14: Visual Test And Function Test
For the safekeeping of the mask the mask container should be used. This also applies to masks with installed filters, except CO and NO filters. MSA rubber products are protected by an anti-aging agent that can become visible as a light coating. This coating is harmless and can be removed during cleaning. -
Page 15: Ordering Information
Ordering Information Ordering Information Exploded View Fig. 3 Full face mask exploded view Nose cup valve seat Valve assembly P Nose cup valve disc Cover P, Elite Nose cup [without valves] Clamp Head harness Inhalation valve seat Elite Carrying strap Inhalation valve disc AutoMaXX connector Ultra Elite Connector, Elite... -
Page 16: Full Face Mask
Ultra Elite PS-MaXX – large Transponder 10100876 ESA Plug-in Connector Ultra Elite PF-ESA 10031393 Ultra Elite PF-ESA – small 10031392 Ultra Elite PF-ESA – silicone 10031396 Ultra Elite PF-ESA-EZ 10031391 Ultra Elite-PF-ESA-EZ – small 10031390 Ultra Elite Full Face Mask – Positive Pressure... -
Page 17: Accessories
Special tool [for replacing exhalation valve and speech diaphragm] D2055038 Exhalation valve closure D2056703 Mask hanger [package of 4] D2055753 Mask tightness test kit [for more MSA testing instruments refer to D6063705 www.msa.europe.com] Carrying bag Elite D2055400 Carrying container Elite... - Page 18 For local MSA contacts, please visit us at MSAsafety.com Because every life has a purpose...
