Pentair
375 5th Ave., New Brighton, MN 55112
Phone: (651)766-6300 -OR- 800-424-9776 Fax: 800-323-6496
www.hypropumps.com
EU Authorized Representative:
Original Instruction Manual
KEEP FOR FUTURE REFERENCE
9742P Series
Close-Coupled, AC Electric Motor-Driven,
Self-Priming Poly Centrifugal Pump
QNET BV Hommerterweg 286
EC
REP
6436 AM Amstenrade, The Netherlands
KvK Zuid-Limburg 14091511
Hypro Series 9742P
Form L-1568
Rev. B
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pentair Hypro 9742P Series
Summary of Contents for Pentair Hypro 9742P Series
- Page 1 Rev. B Original Instruction Manual KEEP FOR FUTURE REFERENCE 9742P Series Close-Coupled, AC Electric Motor-Driven, Self-Priming Poly Centrifugal Pump Pentair 375 5th Ave., New Brighton, MN 55112 Phone: (651)766-6300 -OR- 800-424-9776 Fax: 800-323-6496 www.hypropumps.com EU Authorized Representative: QNET BV Hommerterweg 286...
-
Page 2: Table Of Contents
Contents EU Language ..................................3 Introduction.................................4 Description..............................4 Intended Uses................................4 Purpose of Manual..............................4 Misuses................................4 Pump Identification..............................5 Pump Technical Data..............................5 Fluid Pumping Application............................6 Tools................................6 Lifting, Transport, and Intermediate Storage.......................6 Assembly and Installation................................7 Assembly............................7 Installation............................7 Plumbing Diagram..............................9 Commissioning, Start-Up, Operation, Shutdown........................10 Information.............................10 Start-Up, Operation, Shutdown..........................10 Maintenance and Servicing..............................13 Information..........................13 Disposal...........................13... -
Page 3: Eu Language
EU Languages DO NOT attempt to install or operate your pump before reading the manual. Original copies of the manual for Hypro pumps are provided in English. To find a copy in your native language, go to www.hypropumps.com. Vor dem Ablesen des Handbuches versuchen Sie NICHT, Ihre Pumpe zu installieren. Originale des Handbuches fur Hypro-Pumpen werden auf englisch zur Verfugung gestellt. Zu eine Kopie in Ihrer Muttersprache finden, zu www.hypropumps.com zu gehen (German) N’essayez pas d’installer votre pompe avant de lire le manuel. -
Page 4: Introduction
Introduction Description Hypro centrifugal pumps are designed for creating and boosting pressure in fluid circuits. The pump operates by taking in fluid from the inlet port after which it is slung by the impeller and expelled through the outlet port. Construction features include housings, impellers and seals which come in a variety of materials in order to be resistant to a range of chemicals. Standard models of centrifugal pumps rotate counterclockwise, when looking at the front of the pump. Intended Uses Hypro centrifugal pumps are intended for creating or boosting dynamic pressure in approved fluids. Hypro centrifugal pumps should never be used to pump liquids above 140°F (60°C), or below 34°F (1°C). Any uses outside of those specified in this manual are considered misuses and are prohibited. Contact Hypro technical service with any questions regarding specific acceptable uses. -
Page 5: Pump Technical Data
Horsepower Phase (Volts) (Amps) 9742P-050SPT (150) [568] (47) [3.2] (110) [50] Single 19.4 THIS DRAWING IS THE PROPERTY OF PENTAIR LTD, SYM. CHARACTERISTIC TYPE Ppk/Cpk MIN PART VOLUME PART WEIGHT 2" NPT AND WITHOUT WRITTEN AUTHORIZATION, IMPORTANT > 1.00 MUST NOT BE COPIED OR COMMUNICATED SIGNIFICANT >... - Page 6 - 6 -...
-
Page 7: Fluid Pumping Application
Fluid Pumping Applications Pump Materials Compatibility Application Impeller Pump Housing Seal Polypropylene Polypropylene Ceramic Weed Control Chemicals Insect Control Brush Control Pest Control Chemicals and Fumigants Liquid Fertilizers Powdered Fertilizers Fluid Transfer Acids Table 1 Flammable liquids as well as the following fluids should never be put through any Hypro pump: • Sewage • Potable water Tools The Hypro centrifugal pumps and mounting assemblies are designed with Imperial (inch) bolts, however, there are many metric (mm) sizes which will work with these mounts. In most cases, an adjustable spanner wrench can also be used. -
Page 8: Assembly And Installation
Figure 1 Transport • All Hypro pumps are capable of being transported by air, sea, rail or motor vehicle. When the pump is shipped, ensure that the pump is moved in accordance with local and national laws and is properly secured to prevent unwanted movement which could cause damage to person or property. Prior to shipping, all fluids should be removed from the pump. - Page 9 • It is the intaller’s responsibility that AC electric-drive motors, Hypro Pumps, and metalwork of support structures are bonded to earth (ground), per local and national standards, to prevent a buildup of static electricity. • When a main electrical supply is needed to power electric-driven motors, installers are responsible for ensuring that a supply disconnect device, capable of isolating the machine from its electicity supply, be provided. •...
-
Page 10: Plumbing Diagram
Plumbing Diagram - 10 -... -
Page 11: Commissioning, Start-Up, Operation, Shutdown
Commissioning, Start-Up, Operation, Shutdown Before attempting to start your pump, the following must be understood and followed to ensure safe operation. Information • When running Hypro centrifugal pumps, it is essential that operators use hearing protection as the sound levels can reach levels of 80 decibels. -
Page 12: Maintenance And Servicing
Maintenance and Servicing Information • All maintenance should be done when machinery is stationary and has been isolated from its energy sources. It is dangerous to perform maintenance while machinery is still connected to its power source. Machinery should be isolated from its electrical, hydraulic or gas engine power source. -
Page 13: Maintenance, Routine Servicing, And Inspection
Maintenance, Routine Servicing, and Inspection PREVENTATIVE MAINTENANCE CHECKLIST Check Every Use Daily Weekly 100 Hrs. Monthly 6 Months Water Leaks Plumbing • Each system’s maintenance cycle will be exclusive. If system performance decreases, check immediately. • Duty cycle, temperature, quality, type of fluid being pumped, and inlet feed conditions all affect the life of assemblies and service cycle. Troubleshooting Before attempting to service your pump, be sure that it is disconnected from all energy sources. Symptom Probable Cause(s) Corrective Action... -
Page 14: Replacement Parts
Qty. Qty. Description Number Description DRAWING BASED ON ASME Y14.5M-1994 SYM. CHARACTERISTIC TYPE Ppk/Cpk MIN THIS DRAWING IS THE PROPERTY OF PENTAIR LTD, PART VOLUME PART WEIGHT AND WITHOUT WRITTEN AUTHORIZATION, O-Ring 1721-0211 O-Ring IMPORTANT > 1.00 MUST NOT BE COPIED OR COMMUNICATED... -
Page 15: Declaration Of Incorporation
EC Declaration of Incorporation Pentair Flow Technologies, LLC Manufacturers Name: Manufacturers’ Address: 375 Fifth Avenue NW, New Brighton, MN 55112, USA Declare that the partially complete machinery described below conforms to applicable health and safety requirements of Parts 1 of Annex I of Machinery Directive 2006/42/EC. This partly completed machinery must not be put into service until the equipment into which it is to be incorporated has been declared in conformity with the provisions of this directive. - Page 16 Contact Hypro Service Department at 800-468-3428 to receive a Return Merchandise Authorization number (RMA#). Returns are to be shipped with the RMA number clearly marked on the outside of the package. Hypro shall not be liable for freight damage incurred during shipping. Please package all returns carefully. All products returned for warranty work should be sent shipping charges prepaid to: HYPRO / PENTAIR Attention: Service Department 375 Fifth Avenue NW New Brighton, MN 55112 For technical or application assistance, call the Hypro Technical/Application number: 800-445-8360, or send an email to: technical@ hypropumps.com.
