Pentair HYPRO 1532C-6SP Installation, Operation, Repair And Parts Manual

Pentair HYPRO 1532C-6SP Installation, Operation, Repair And Parts Manual

Self-priming cast iron centrifugal pumps

Advertisement

Installation, Operation, Repair and Parts Manual
Hypro Self-Priming Cast Iron Centrifugal Pumps handle
big, high-capacity, liquid transfer jobs with ease. Use them
for transferring water, liquid fertilizers, and other chemicals
compatible with pump materials. Make short work of other
1532C-6SP
Pump with 6.5 hp PowerPro gas engine
1532C-160HSP
Pump with Honda GX160 gas engine
3430-0673CSP
Pump only for 3/4" shaft gas engine mount
9232C-SP
Pump with pedestal
9732C-SPX
Pump with 184TC NEMA flange
9332C-HM1C-SP Pump with Hypro HM1 hydraulic motor
9332C-HM5C-SP Pump with Hypro HM5 hydraulic motor
Max Flow Rate:.......................................................170 GPM
Max. Pressure: .......................................................... 42 PSI
Max. Total Head: ...........................................................97 ft.
Ports: ..................................................................2" NPT Inlet
Engine: ..........................PowerPro 6.5 HP or Honda GX160
Hydraulic Motor: ...........................Hypro HM1 or HM5 Motor
Note: Unit is not shipped with oil. Please add oil to engine prior to operating.
California Proposition 65 Warning -- This product and related accessories contain chemicals known to the
State of California to cause cancer, birth defects or other reproductive harm.
2" Model
2" NPT Outlet
Description
farm jobs: filling nurse tanks, watering seedbeds, and
transferring liquids. This self-priming model makes it ideal
for de-watering applications.
1533C-13SP
1533C-13ESP
1533C-390EHSP Pump with Honda GX390 gas engine
3430-0674CSP
9233C-SP
9733C-SPX
9333C-GM10-SP Pump with Marzocchi hydraulic motor
Max Flow Rate:....................................................... 330 GPM
Max. Pressure: .......................................................... 60 PSI
Max. Total Head: ......................................................... 140 ft.
Ports: .................................................................. 3" NPT Inlet
Engine: .............. PowerPro 9.0 or 13.0 HP or Honda GX390
Hydraulic Motor: ...................... Marzocchi ALM2 Gear Motor
1
Self-Priming Cast Iron
Centrifugal Pumps
3" Model
Pump with 13 hp PowerPro gas engine
Pump with 13 hp electric start PowerPro gas
engine
Pump only for 1" shaft gas engine mount
Pump with pedestal
Pump with 215TC NEMA flange
Form L-1510
Rev. D
3" NPT Outlet

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYPRO 1532C-6SP and is the answer not in the manual?

Questions and answers

Summary of Contents for Pentair HYPRO 1532C-6SP

  • Page 1 Self-Priming Cast Iron Centrifugal Pumps Form L-1510 Rev. D Installation, Operation, Repair and Parts Manual Description Hypro Self-Priming Cast Iron Centrifugal Pumps handle farm jobs: filling nurse tanks, watering seedbeds, and big, high-capacity, liquid transfer jobs with ease. Use them transferring liquids.
  • Page 2: Plumbing Installation

    WARNING: Do not pump flammable or explosive fluids 5. Periodically inspect the pump and the system such as Gasoline, Fuel Oil, Kerosene, etc. Do not use components. Perform routine maintenance as required in explosive atmospheres. The pump should be used (see Maintenance section).
  • Page 3: Operation And Maintenance

    Please Note: It is illegal to ship or transport any 2. Before returning unit for repair, drain out all liquids and hazardous chemicals without United States flush unit with neutralizing liquid. Then, drain the pump. Environmental Protection Agency Licensing. Attach a tag or include a written notice certifying that this has been done.
  • Page 4 Assembly Instructions INITIAL ASSEMBLY – gas engine, C-faced electric motor, or ped- estal mount Note: Prior to assembly, visually inspect pump outlet for impeller spacer. Pumps are supplied with a metal shim inserted into the pump outlet and across the impeller face to ensure proper impeller spacing. If the shim is in place, proceed to step 10.
  • Page 5 Assembly Instructions clamp sits in drive sleeve slot. Leave bolts and nuts finger tight. ***Some clamps may not have an integral key. (Figure 7) 11. Apply an anti-seize compound to engine, motor, or pedestal shaft. 12. Install gas engine, c-faced electric motor, or pedestal into pump drive sleeve. Align keyway of drive source with slot in drive sleeve.
  • Page 6 Disassembly Instructions DISASSEMBLY – gas engine, C-faced electric motor, or pedestal mount 1. Remove two-bolt clamp and bolts. (Figure 9) 2. Remove (4) mounting bolts between pump adapter and engine, motor, or pedestal. (Figure 10) 3. Remove engine, motor, or pedestal. Drive source may need to be pried off. Use caution not to damage drive source or pump.
  • Page 7 Service Instructions WEAR PLATE: Inspect wear plate for excessive wear, surface grooves or impeller contact. Replace if needed. (Figure 13) 1. Remove two 3/8” stainless steel screws from wear ring. (Figure 14) Note: Older models have acorn nuts and plastic washers on the front of the pump.
  • Page 8: Mechanical Seal

    Service Instructions MECHANICAL SEAL: 1. Remove seal and spring from impeller/drive sleeve assembly. (Figure 16) 2. Clean drive sleeve surface. Surface may be cleaned with 400 grit or higher sandpaper. If sleeve surface is worn, grooved or pitted, replace drive sleeve. Note: Worn or damaged impeller/drive sleeve may cause the pump to under perform or become unbalanced, causing mechanical seal damage.
  • Page 9 Reassembly Instructions REASSEMBLY: 1. Insert a shim between the impeller vanes and pump wear plate. A shim 1/2” wide and 0.040” to 0.050” is required. Plastic or steel banding can be used as a shim. Verify banding thickness prior to use. Place shim material into the pump through the outlet port.
  • Page 10: Running The Engine

    Service Instructions RUNNING THE ENGINE MAINTENANCE Refer to engine operation section of this manual for start- PUMP LUBRICATION ing and operating instructions. Pump liquid end does not require any grease or oil for Pump performance varies depending on engine RPM. lubrication.
  • Page 11: Engine Operation

    Pump Engine Operation and Maintenance Engine Safety Precautions: Add Gasoline Fill gas tank with clean, fresh gasoline. This should be Fire and explosion hazard. Gasoline can unleaded fuel that has an octane rating of 86 or higher. explode. Store gasoline away from the engine. Add gaso- Do not fill the tank to overflowing.
  • Page 12: Engine Maintenance

    Service Instructions Engine Maintenance Engine Troubleshooting If the engine won’t start: Air Filter • Check that there is gas in the tank. The air filter should be checked every month for dust • Make sure the fuel valve is “ON” and that the engine and dirt accumulation. Every 6 months, the filter element switch is “ON.”...
  • Page 13: Performance Information

    Performance Information 2” & 3” Gas Engine Drive, Pedestal Pump, Pump only for Gas Engines 9723C-SPX English Units English Units 1532C-6SP, 1532C-160HSP, 9232C-SP, 3430- 0673CSP 9733C-SPX English Units 1533C-13ESP, 1533C-390EHSP, 1533C-13SP, 1533C-9SP, 9233C-SP, English Units 3430-0674CSP 2” Hydraulic Motor Drive 9332C-HM1C-SP 9332C-HM5C-SP English Units...
  • Page 14 Performance Information 9333C-GM10-SP English Units Hyd. Flow...
  • Page 15 1532C-6SP, 1532C-160HSP, 9232C-SP, and 9732C-SPX Self-Priming Cast Iron Centrifugal Pumps Ref. Ref. Qty. Part No. Description Qty. Part No. Description 2210-0160 Cap Screw, 5/16-18 2120-0046 Mechanical Seal (FKM), 1” 2260-0051 Lockwasher, 5/16 1710-0017 Gasket 2404-0363 Inlet Flange (2” NPT) 0750-9032C Mounting Flange (Gas Engine) 1700-0218 Flapper Valve Assembly...
  • Page 16 1533C-13SP, 1533C-13ESP, 1533C-390EHSP, 9233C-SP, and 9733C-SPX Self-Priming Cast Iron Centrifugal Pumps Ref. Ref. Qty. Part No. Description Qty. Part No. Description 2404-0361 Discharge Flange (3” NPT) 1420-0033 Shaft Sleeve Clamp Assy. (1”) 2404-0364 Inlet Flange (3” NPT) 1420-0026 Shaft Sleeve Clamp Assy. (1.375”) 0750-9033C Mounting Flange (Gas Engine) 2250-0097 Nut 3/8-24 SS...
  • Page 17 9333C-GM10-SP Self-Priming Cast Iron Centrifugal Pumps QTY. Part No. Description QTY. Part No. Description 2210-0161 Cap Screw, 3/8-16 0750-9033C Mounting Flange 2260-0052 Lockwasher, 3/8 2210-0019 Hex Head Bolt 2404-0364 Inlet Flange (3" NPT) 2260-0006 Lockwasher 1700-0220 Flapper Valve Assembly 2250-0097 Hex Nut (3/8-16) 2406-0043 External Square Drain Plug (1/2"...
  • Page 18 This page intentionally left blank...
  • Page 19 This page intentionally left blank...
  • Page 20: Return Procedures

    Returns are to be shipped with the RMA number clearly marked on the outside of the package. Hypro shall not be liable for freight damage incurred during shipping. Please package all returns carefully. All products returned for warranty work should be sent shipping charges prepaid to: HYPRO / PENTAIR Attention: Service Department 375 Fifth Avenue NW...
