GSM/GPRS/GPS TRACKER
MANUAL
Preface
Thank you for purchasing the tracker. This manual shows how to operate the device
smoothly and correctly. Make sure to read this manual carefully before using this
product. Please note that specification and information are subject to changes
without prior notice in this manual. Any change will be integrated in the latest release.
The manufacturer assumes no responsibility for any errors or omissions in this
document.
1

Advertisement

loading

Related Manuals for Coban GPS102-B

Summary of Contents for Coban GPS102-B

  • Page 1 GSM/GPRS/GPS TRACKER MANUAL Preface Thank you for purchasing the tracker. This manual shows how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. Please note that specification and information are subject to changes without prior notice in this manual.
  • Page 2 1. Summary Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any movable device by SMS ,app and internet It has newest advanced technology of gps and agps dual positioning Content Specs Dim. 74*43*31MM 140g(6400ma) Weight 95g(4400ma)
  • Page 3 2.Led indicator status LED INDICATOR STATUS MEANING Red light continuously work Charging Red light not lit Fully charged Green light Flashing Success get GSM singnal Green light continuously lit Searching GSM signal 3. Operational Notices: 1).GPS tracking can be worked outdoor. Must have mobile phone gsm signal and have GPS signal, It can block GPS satellite signal when there are metal or building above the GPS tracker 2).Pls make sure GSM 2g SIM card or compatibility 2G GSM network sim card,...

  • Page 4: Quick Using

    Quick using sending message “time zone123456 time”,time is local time zone,then send“smslink123456” to sim card in tracker ,tracker reply positioning information Picture (1) have gps signal Picture (2) no gps signal Pic(1)：Replied real-time tracking information  Lat:22.67533 lon:114.03913: Positioning of the latitude and longitude ...
  • Page 5 IPHONE---download-- installation app 2) Download iOS APP: app store search---dagps---Install the dagps APP 4.2: login platform positioning 1)Open www.gps110.org Use tracker ID login, default password 123456. You can tracker device,it is ok...
  • Page 6 PC login APP login It is Real time positioning,every 2min upload position by default,you can change upload position time interval 4.2NOTE:If you insert the correct SIM card and open GPRS, device in outdoor, still not online.Please set the APN commands we have two methods to find out apn content:ask simcard company or put sim card into cell phone to find out APN SMS:...

  • Page 7: Positioning Mode

    Registration fill in Click vehicle list add device If you add device more than two , continue to add ID number 5. positioning mode...
  • Page 8 【Mode 1】：real-time positioning,Trajectory mode (default) dagps APP→ point instruction →mode switch→trajectory mode→send It is every 2mins/1 times positioning,(work 24 h) 【Mode 2】：Roll call positioning,save power mode Dagps APP-point instruction→mode switch→save power mode →send→positioning→location If you want to locate, you point locate . If you don't want to position it, device into save power automatically,( work 8 days) sms mode positioning...
  • Page 9 EXAMPLE  NAME COMMAND apn123456 apn Name apn123456 cmnet Set apn apn123456 apn name user password Apn123456 cmnet cmwap 66666 adminip123456 IP port Adminip123456 110.92.64.21 7018 Set IP /DNS Adminip123456 www.gps110.org port Adminip123456 DNS port 7018 parameter Check123456 Get device status...
  • Page 10 Example REPLY INSTRUCTION Set time zone time zone123456 local time Time zone ok Set time zone(half time zone) Time zone123456 8 30 time zone ok position smslink123456 Get adress Set admin number admin123456 mobile number admin ok Cancel admin number noadmin123456 mobile number noadmin ok set move alarm...
  • Page 11 Instructions/Solutions Please check if device has electricity and charge line to Fail to turn on be rechargeable  Please check if SIM card installed correctly. No GSM signal  Please check if SIM card is 2G GSM network.  Cancel Sim card PIN code ...
