TB0C Register
Bit 7
Name TB0ON
R/W R/W
POR 0
Bit 7 TB0ON: Time Base 0 Enable Control
0: Disable
1: Enable
Bit 6~3 Unimplemented, read as "0"
Bit 2~0 TB02~TB00: Time Base 0 time-out period selection
000: 2
001: 2
010: 2
011: 2
100: 2
101: 2
110: 2
111: 2
TB1C Register
Bit 7
Name TB1ON
R/W R/W
POR 0
Bit 7 TB1ON: Time Base 1 Enable Control
0: Disable
1: Enable
Bit 6~3 Unimplemented, read as "0"
Bit 2~0 TB12~TB10: Time Base 1 time-out period selection
000: 2
001: 2
010: 2
011: 2
100: 2
101: 2
110: 2
111: 2
