Page 6: Introduction
INTRODUCTION Welcome BAIN-MARIE CABINETS INTRODUCTION Future Welcome to the world of FPG! Our products are designed and engineered to Products give you the optimal performance that you deserve with innovative visual Group (FPG) merchandising appeal. We are confident that you will be delighted with your state of the art inline food service cabinet, and that it will become a valued appliance in your store. -
Page 7: Liability Exceptions
Fair wear and tear. Assessment The liability under this warranty is dependent on an assessment by FPG, to determine the defect in workmanship or materials. Time Limit FPG does not guarantee that any service to be performed under this warranty will be carried out within any particular time limit. -
Page 8: Operation
OPERATION Cabinet Layout BAIN-MARIE CABINETS OPERATION 3000 Series The 3000 Series Dry Well Cabinets Bain-marie cabinet has a fixed glass front and sliding glass rear doors. There are no internal shelves, but food dishes are provided in the base. The cabinet lighting and temperature controls are on the back of the cabinet. -
Page 9: Preparation
The longer the doors are open the longer the time to restore normal operating temperature. IN 3B08/12/15 - 9 - © Future Products Group... -
Page 10: Trouble Shooting
TROUBLE SHOOTING FAULT POSSIBLE CAUSE REMEDY Door not in track Install door correctly in track Debris in track Clean door tracks (see cleaning) Doors are not sliding smoothly Apply food grade lubricant to Lack of lubricant door track The mains isolating switch on the wall, circuit breaker or Turn isolating switch circuit fuses are off at the power... -
Page 11: Cleaning
The left door should be in the inner slots, and the right door in the outer slots. Sliding door tracks should be vacuumed out regularly to keep doors sliding freely. Continued on next page IN 3B08/12/15 - 11 - © Future Products Group... -
Page 12: Interior
Interior BAIN-MARIE CABINETS CLEANING Cabinet Well To clean the hot cabinet well, first lift out the dishes and dividers and then sweep out or vacuum away loose debris. This cabinet is a dry well unit, so the well is not waterproof. Do NOT pour water into the well as it will leak out and damage insulation and electrical wiring. -
Page 13: Installation
Before connecting to the power supply, check that the local supply is correct to that shown on the rating plate, located on the rear of the cabinet. Continued on next page IN 3B08/12/15 - 13 - © Future Products Group... -
Page 14: Isolation
Setting Up cont. BAIN-MARIE CABINETS - INSTALLATION Isolation If the cabinet is not connected by a plug and socket, but is hard wired to the mains supply, a means of isolation must be provided. If a plug and socket are used, they should still be accessible after the cabinet is installed. -
Page 15: Livery
The dowel should be progressively withdrawn as the strip is inserted. Note: Most metals are too rigid for insertion in this position. Maximum strip thickness is 0.75mm. See Mechanical Drawings for dimensions. IN 3B08/12/15 - 15 - © Future Products Group... -
Page 16: Servicing
SERVICING Control Gear BAIN-MARIE CABINETS SERVICING Location The electrical control gear is located in the top of the cabinet. Remove six screws to remove the top plate. The chassis has a light switch, a thermostat, a thermometer and a protective fuse. The incoming mains cable is terminated on a connecting block. -
Page 17: Heating
Fault Finding. Re-assemble If the heater is now working, re-assemble the food dishes and dividers inside the cabinet. IN 3B08/12/15 - 17 - © Future Products Group... -
Page 18: Door Seals
Door Seals BAIN-MARIE CABINETS SERVICING Seal The doors should be removed to allow the old seals to be removed and the new Replacement ones fitted. See the Cleaning section for details. Sliding Doors Each sliding door has a seal between the door and the cabinet end panel. The seal slides into a groove in the door extrusion, and can be withdrawn and replaced, if damaged. -
Page 19: Specifications
SPECIFICATIONS Mechanical BAIN-MARIE CABINETS SPECIFICATIONS CABINET MODEL IN 3B08 IN 3B12 IN 3B15 Height 761 mm 761 mm 761 mm Width 803 mm 1203 mm 1503 mm Depth 663 mm 663 mm 663 mm Dry Weight 45 kg 60 kg... -
Page 20: Compliance
Test Conditions >65°C 23°C Ambient with 60% RH Improvements BAIN-MARIE CABINETS SPECIFICATIONS Ongoing FPG reserves the right to change specifications and construction, as part of Development ongoing product improvement. Part No.16894 Rev. G March 2014 - 20 - 3000 Series Cabinets... -
Page 21: Electrical Wiring Diagrams
ELECTRICAL WIRING DIAGRAMS Model: IN 3B08 Inline 3000 Series, 800mm Dry Well Bain-Marie Cabinet Model: IN 3B12 Inline 3000 Series, 1200mm Dry Well Bain-Marie Cabinet Continued on next page IN 3B08/12/15 - 21 - © Future Products Group... -
Page 22: Model: In 3B15
ELECTRICAL WIRING DIAGRAMS, Continued Model: IN 3B15 Inline 3000 Series, 1500mm Dry Well Bain-Marie Cabinet Part No.16894 Rev. G March 2014 - 22 - 3000 Series Cabinets... -
Page 23: Spare Parts
Number the label fixed to the control panel. This serial number will enable FPG to trace details of the build specification of your particular cabinet, and hence ensure that spare parts are fully compatible. To satisfy warranty conditions, and ensure optimum performance, use only FPG supplied spare parts. -
Page 24: Mechanical Drawings
MECHANICAL DRAWINGS Dimensions BAIN-MARIE CABINETS MECHANICAL DRAWINGS IN-3B08 Continued on next page Part No.16894 Rev. G March 2014 - 24 - 3000 Series Cabinets... -
Page 25: In-3B12
IN-3B12 Continued on next page IN 3B08/12/15 - 25 - © Future Products Group... -
Page 26: In-3B15
IN-3B15 Cabinet The following drawings show the common overall dimensions for 800mm, Variants 1200mm and 1500mm cabinets. Livery Top Insert 749 / 1149 / 1449 mm long x 50 mm wide Colour / Text Inserts Max. thickness Bottom Insert 754 / 1154 / 1454 mm long x 134 mm wide 0.75 mm If custom livery is applied to the cabinet, the insert material must be flexible, such as Formica decorative laminate or plastic sheet. -
Page 27: Bench Cut-Outs
The following diagram shows the size and location of the holes, required for the Mounting cabinets to sit on the bench. The holes are always in the same location, with reference to the back, right hand corner of all cabinets. IN 3B08/12/15 - 27 - © Future Products Group... - Page 28 Part No.16894 Rev. G March 2014...
