SBC81200 LGA775 CPU Card Series User's Manual
1.2

Specifications

®
Chipset: Intel 865G
CPU Socket: LGA775
®
CPU: Intel Pentium 4 FSB 533MHz/800MHz
L2 Cache: Integrated in CPU
BIOS: Phoenix AwardBIOS Rev.6.00
System Memory:
2 x 184-pin DDR DIMM sockets
Maximum up to 2GB DDR
IDE Interface: 2 bus mastering EIDE up to four devices, Ultra
DMA 100 supported
FDD Interface: Supports up to 2 drives
Serial Ports:Two 16550 UARTs ports with 16 byte as two RS232.
Parallel Ports: One parallel port with ECP/EPP/SPP supported
VGA Controller:
VGA On-chip Intel
Supports up to 2048x1536 at 75 Hz resolution on
non-interlaced CRT monitors
18Bits LVDS LCD(Optional)
Ethernet:
Intel 82547GI is Giga LAN controller.
Intel 82562ET is 10/100Mbps LAN controller
Wake On LAN support
2
®
865G.
Introduction
