SBC81200 LGA775 CPU Card SeriesUser's Manual
USB Interface:
4 USB ports; USB Spec. Rev. 2.0 compliant.
Audio :
Realtek ALC202A
Compact Flash:
Type II Socket
Mini PCI (Option):
Socket-s 124 Pin
Disk On Chip (Option) :
Socket IC 32 Pin
Hardware Monitoring:
Controller: Winbond W83627HG-AW detection of CPU
temperature, System temperature, Power failure and Fan
speed.
Watchdog Timer:
Generates a system reset
Software programmable time interval and hardware
reset only.
255 level, 256 seconds
Dimensions:122(W) x 338(L) mm
NOTE:Specifications are subject to change without notice.
1.3

Utilities Supported

®
Intel 865G Utility and Drivers
Ethernet Utility and Drivers
VGA Drivers
Audio Drivers
Introduction 3
