1. Functional Overview

Front – fi g. 1
Display
Soft key 1
Soft key 2
Up/down selector
Left/right selector
Icon for system alarm
GB
Icon for communication with Master Controller
Icon for switch to 230V power supply
Icon for low battery level
Note: The Remote Controller has a self-explanatory menu structure,
and all settings are easily carried out with the up/down and left/right
selectors in combination with the functions of the soft keys, which are
shown above them in the display.
Back – fi g. 2
Back plate/docking station
Battery compartment
Screw hole for wall mounting
Screw and wall plug
Note: Remove the strip to connect the enclosed batteries.

2. Installation

Note:
• Install the Remote Controller after you have installed all the Room
Thermostats, see fi g. 5-b.
• Remove the strip to connect the enclosed batteries.
• Carry out the assignment of the Remote Controller to the Master
Controller within a distance of 1½m.
• When the back light in the display is out, the fi rst touch of a button
only activates this light.
Activate Install mode on the Master Controller - fi g. 3
• Use the menu selection button
The install LED
• Activate Install mode by pressing OK
ON.
4
to select the Install mode.
fl ashes.
. The install LED
CFRC REMOTE CONTROLLER
goes
