SETUP
1. Platter and drive belt installation
Please remove drive belt from accessories box and install it as shown in the following ilustration. Put the felt
mat on the top of the platter.
2. Cartridge installation, stylus exchange
* If you purchased this turntable in a package that included the cartridge, this has already been done for
you.
Install the cartridge into the aluminium headshell, using the appropriate hardware included with your
cartridge. All cartridges with half inch mounting holes can be fitted.
Connect the cartridge as indicated below:
•
White
•
Red
•
Green
•
Blue
For correct cartridge alignment, use the two-point cartridge alignment protractor provided with your T1
accessories. If unfamiliar with two-point setup, please refer to your dealer.
A damaged or worn stylus may harm your record collection and should be replaced.
Please remove stylus protection before pulling the stylus from the cartridge and replace for a new one.
Stylus type is exchange for pre-mounted cartridge Ortofon OM 5e: Stylus OM 5e. If in doubt, consult your local
dealer or distributor.
3. Vertical Tracking Force setting (VTF)
* This setting is only neccessary when you decided to repalce your cartridge. For factory fitted cartridge, VTF
left channel L+
right channel R+
right channel R-
left channel L-
