- Page 1 INSTRUCTIONS FOR USE Pro-Ject T2 Super Phono...
-
Page 2: Table Of Contents
Dear Music Lover, Congratulations and thank you for choosing Pro-Ject Audio Systems record player. Your T2 Super Phono turntable has been handcrafted and rigorously tested by skilled technicians to give you years of enjoyable, trouble-free service. If you require additional assistance, please contact your dealer. - Page 3 SINGLE ADAPTOR ALLEN KEY 1,5mm COUNTERWEIGHT no. 105 (FOR CARTRIDGE WEIGHT 5 – 11.5g) TWO-POINT CARTRIDGE ALIGNMENT PROTRACTOR CONNECTION CABLE (CONNECT IT E RCA) SETUP GUIDE UNIVERSAL POWER SUPPLY © Pro-Ject Audio Systems · Pro-Ject T2 Super Phono · Revision 22.05.2024...
-
Page 4: Product Illustrations
© Pro-Ject Audio Systems · Pro-Ject T2 Super Phono · Revision 22.05.2024... -
Page 5: Setup
Please remove stylus protection before pulling the stylus from the cartridge and replace for a new one. Stylus type is exchange for pre-mounted cartridge Sumiko Rainier: Stylus Sumiko Rainier. If in doubt, consult your local dealer or distributor. © Pro-Ject Audio Systems · Pro-Ject T2 Super Phono · Revision 22.05.2024... -
Page 6: Vertical Tracking Force Setting (Vtf)
3. Vertical Tracking Force setting (VTF) The T2 Super Phono comes with the counterweight already assembled on the tonearm, and the tracking force is factory pre-adjusted. To adjust or fine tune the tracking force manually, loosen the hexagonal screw on top of the counterweight (7) using the allen key provided. -
Page 7: Maintenance And Cleaning
Sumiko Rainier recommended tracking force 20mN = anti-skating set to 2 (middle position). You can adjust the anti-skating by rotating the anti-skating setting screw to the left or right. Anti-skating setting screw © Pro-Ject Audio Systems · Pro-Ject T2 Super Phono · Revision 22.05.2024... -
Page 8: Connection To The Amplifier
For detailed product information regarding Pro-Ject Audio phono amplifiers please refer to the Pro-Ject web site www.project-audio.com. The recommended load impedance for the factory fitted cartridge is: 47kohms /MM-input © Pro-Ject Audio Systems · Pro-Ject T2 Super Phono · Revision 22.05.2024... -
Page 9: Technical Parameters
6.5g Technical specifications MM phono pre-amplifier Gain 42dB Output voltage typically 630mV/1kHz at 5mV/1kHz input Input impedance 47kohms/50pF Noise floor -75dB RIAA-equalisation curve accuracy 20Hz-20kHz / max. 0.3dB © Pro-Ject Audio Systems · Pro-Ject T2 Super Phono · Revision 22.05.2024... -
Page 10: Troubleshooting, Warranty, Service
This guide was produced by: Pro-Ject Audio Systems notice as deemed necessary to uphold the ongoing Copyright © 2024. All rights reserved. process of technical development. © Pro-Ject Audio Systems · Pro-Ject T2 Super Phono · Revision 22.05.2024... - Page 11 EMC: EN301489-1 V2.2.0: 2017-03, EN301489-17 V3.2.0:2017-03, EN55032:2015, EN55035:2017, EN61000-3-2:2014, EN61000-3-3:2013 Radio Spectrum: EN300328 V2.1.1 (2016-11) Pro-Ject Audio Systems a division of Audio Tuning GmbH 1050 Vienna, Austria, Margaretenstrasse 98 info@project-audio.com © Pro-Ject Audio Systems · Pro-Ject T2 Super Phono · Revision 22.05.2024...
-
Page 12: Exploded View Of The Packaging
© Pro-Ject Audio Systems · Pro-Ject T2 Super Phono · Revision 22.05.2024... - Page 13 T2 Super Phono | Setup Guide Getting started: • Make sure to have enough space to unpack your turntable. • Always unpack and set up in a clean environment. • Please Do NOT throw away the packaging! If you need service or want to return your product, please send it in the original packaging including all inserts.
- Page 14 Should you encounter a problem which you are not able to alleviate or identify despite the above information, please contact your dealer for A Pro-Ject Audio Systems warranty relates to claims of defects in materials and/or workmanship at the time of purchase. It does not cover: further advice.
- Page 15 Ject em: www.project- Trouvez votre revendeur ici : audio.com/en/find-a-dealer/ сайтами www.overton.ru или ンドエムホールディングスまでお dealer https://www.project- audio.com/en/find-a-dealer/ todo el mundo. Encuentre su audio.com/en/find-a-dealer/ project-audio.fr/revendeurs/ www.projectaudio.ru 問い合わせください。 audio.com/en/find-a-dealer/ audio.com/de/haendler-suche distribuidor más cercano aquí: www.project-audio.com/en/find-a- dealer/ T2 Super Phono SGT-033...
- Page 16 Questa guida è stata prodotta da: Pro-Ject Audio La presente guía ha sido producida por Pro-Ject Este manual foi produzido pela: Pro-Ject Audio Ce guide a été conçu par : Pro-Ject Audio Systems Denna guide är framtagen av: Pro-Ject Audio 本指南由：Pro-Ject Audio Systems 制作...
- Page 17 PRODUCT INFORMATION T2 Super Phono Walnut: Satin White: Audiophile Turntable with Premium Phono Preamp Gloss Black: MSRP $649 • User-selectable premium MM phono preamp with high- Speed: 33/45rpm (electronic speed change) grade dual-stage split-passive circuitry Principle: Belt-driven sub-platter design •...
- Page 18 PRODUCT INFORMATION T2 Super Phono - A New Contender The T2 Super Phono turntable/preamp combination sensibly enhances critically acclaimed formula. It introduces new audiophile features & sets a higher standard of performance in its price range! Top-Quality Materials The elegantly crafted CNC-machined plinth has been expanded in size to enhance stability &...
- Page 19 PRODUCT INFORMATION Premium Built-In Phono Stage The T2 Super Phono implements a high-quality dual-stage split-passive MM phono preamp (first seen in our critically acclaimed T2 W). The larger plinth makes way for more & better circuitry in the junction box. We've taken this opportunity to design a circuit...
- Page 20 Sumiko Rainier MM Phono Cartridge Semi-Balanced Phono Cable The T2 Super Phono includes the acclaimed high- Like the T1, the T2 Super Phono is topped-off with value Sumiko Rainier MM phono cartridge which shielded, semi-symmetrical, low-capacitance phono synergizes beautifully with the built-in phono stage. The...
