  • Page 1 Tesira Logic Expander (EX-LOGIC) OPERATION MANUAL April 2019...
  • Page 2 EX-LOGIC PRODUCT DESCRIPTION The Tesira® EX-LOGIC is a half-rack logic box for use with Tesira SERVER and SERVER-IO devices. The EX-LOGIC provides both logic inputs and outputs and, through software, can be configured as a control interface. There are 16 total connections that can be used as inputs or outputs. 12 of the connections are designed as logic connections only and will accept contact closure or 5V TTL when used for logic or sink a maximum of 40V/300mA per output.
  • Page 3 EX-LOGIC FRONT PANEL Setup and Use The Tesira software provides an intuitive interface for setup and programming of the EX-LOGIC. The information supplied by this manual relates to physical connections and device setup. For more details on software setup, please consult the Tesira Help File.
  • Page 4 A 10K Linear Potentiometer or similar value is suggested. Visit www.biamp.com to obtain firmware and software updates related to this product. To speak with an Applications Engineer, please call 1.503.641.7287 or email support@biamp.com.
