- Page 1 AudiaEXPI-4, AudiaEXPO-4 & AudiaEXPI/O-2 Input & Output Expanders Operation Manual Biamp Systems | 9300 S.W. Gemini Drive | Beaverton, OR | 97008 | USA | +1.503.641.7287 | www.biamp.com...
-
Page 2: Table Of Contents
AudiaEXPI-4, AudiaEXPO-4 & AudiaEXPI/O-2 TABLE OF CONTENTS Introduction pg. 3 AudiaEXPI-4 – front panel pg. 4 AudiaEXPO-4 – front panel pg. 5 AudiaEXPI/O-2 – front panel pg. 6 Applications pg. 7-10 Specifications pg. 11 Block Diagrams pg. 12 Warranty pg. 13 CE Declaration pg. -
Page 3: Introduction
INTRODUCTION AudiaEXPI-4 is an input expander that accepts four mic/line analog audio inputs and provides four channels of digital audio output via CobraNet®. AudiaEXPO-4 is an output expander that accepts four channels of digital audio input via CobraNet and provides four mic/line-level analog audio outputs. -
Page 4: Audiaexpi-4 - Front Panel
Trim controls (see below). Rotary Encoder & LCD Display: This control and display are used for initial setup of the AudiaEXPI-4 unit. When power is first applied to the unit, the display will cycle through a product description, followed by a title screen. Press the control to enter setup. Rotate the control to make a selection, then press the control again to edit that selection. -
Page 5: Audiaexpo-4 - Front Panel
CobraNet output blocks. Similar considerations may apply when using AudiaEXPO-4 with other CobraNet compliant systems or devices. AudiaEXPI-4, AudiaEXPO-4, and AudiaEXPI/O-2 can exchange digital audio directly (outside of a system network) using either a simple “cross-over” CAT5 cable or an Ethernet switch. -
Page 6: Audiaexpi/O-2 - Front Panel
CobraNet input/output blocks. Similar considerations may apply when using AudiaEXPI/O-2 with other CobraNet compliant systems or devices. AudiaEXPI-4, AudiaEXPO-4, and AudiaEXPI/O-2 can exchange digital audio directly (outside of a system network) using either a simple “cross-over” CAT5 cable or an... -
Page 7: Applications
This application demonstrates the use of Audia® in a moderately large airport with a central control room and six concourses, each with eight boarding gates. This is a networked system using two Networked Paging Station-1 units, one AudiaEXPI-4 Input Expander unit, one AudiaEXPI/O-2 Input/Output Expander unit in the central control room with an AudiaFLEX unit, two AudiaEXPI-4 Input Expander units, an MCA8050 Multi-Channel Amplifier, and eight Networked Paging Station-1 units in each concourse. - Page 8 APPLICATIONS...
- Page 9 APPLICATIONS Courthouse with multiple courtrooms and hard-disk court recording This application describes a major installation in four courtrooms, each with sound reinforcement of ten inputs. Each courtroom includes an assisted listening system, as well as a centralized multi-track computer hard-disk court recording system and localized sound reinforcement.
- Page 10 APPLICATIONS...
-
Page 11: Specifications
SPECIFICATIONS... -
Page 12: Block Diagrams
BLOCK DIAGRAMS... -
Page 13: Warranty
WARRANTY BIAMP SYSTEMS IS PLEASED TO EXTEND THE FOLLOWING 5-YEAR LIMITED WARRANTY TO THE ORIGINAL PURCHASER OF THE PROFESSIONAL SOUND EQUIPMENT DESCRIBED IN THIS MANUAL 1. BIAMP Systems warrants to the original purchaser of new THIS WARRANTY IS IN LIEU OF ALL OTHER products that the product will be free from defects in material WARRANTIES, EXPRESS OR IMPLIED. -
Page 14: Ce Declaration
DIRECTIVES below except as noted herein. Any alterations to the product not agreed upon and directed by Biamp Systems Corporation will invalidate this declaration. Product Models: EXPI-4, EXPI/O-2, EXPO-4...
