Page 1: Operation Manual
Tesira ® EX-LOGIC Logic and Control Expander Operation Manual May 2012 Biamp Systems, 9300 SW Gemini Drive, Beaverton, Oregon 97008 U.S.A. (503) 641-7287 www.biamp.com... -
Page 2: Table Of Contents
TESIRA EX-LOGIC . . . . . . . . . . . . . . . . . . . -
Page 3: Tesira Ex-Logic
• Connects to Tesira SERVER or SERVER-IO over AVB • Powered by PoE • Plug-in barrier strip connections • Front panel LEDs for device status indications • Half-rack chassis • RoHS compliant and AES grounded • Covered by Biamp Systems’ 5-year warranty... -
Page 4: Front Panel
TESIRA EX-LOGIC FRONT PANEL The front panel of the expander displays four multicolor LEDs that provide information about the status of the expander. Green Yellow Unit is not Power Unit is powered Not applicable Not applicable powered Minor fault is... -
Page 5: Rear Panel
TESIRA EX-LOGIC REAR PANEL 1 – Grounding pin. This pin is for grounding the chassis of the expander 2 – Ethernet data connection. Uses a standard RJ-45 connector with CAT-5, CAT-5e, CAT-6 or CAT-7 cabling. The maximum distance between any unit and an Ethernet switch is 328 feet (100 meters). -
Page 6: Specifications
TESIRA EX-LOGIC SPECIFICATIONS Tesira EX-LOGIC Specifications Logic Input Trigger: Contact-Closure Logic Output Type: Open Collector; or 5V TTL Sink 40V/300mA per output LED Driver: 50V/10mA per output Weight: 2 lbs (1 kg) System Network Connection: Compliance: FCC Part 15B (USA) Power: PoE IEEE 802.3af Class 1... -
Page 7: Fcc Compliance
FCC COMPLIANCE FCC NOTICE - CLASS A DIGITAL DEVICE NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 8: Warranty
ORIGINAL PURCHASER OF THE PROFESSIONAL SOUND EQUIPMENT DESCRIBED IN THIS MANUAL 1. Biamp Systems warrants to the original purchaser of new products that the product will be free from defects in material and workmanship for a period of 5 YEARS from the date of purchase from an authorized Biamp Systems dealer, subject to the terms and conditions set forth below. -
Page 9: Ec Declaration
DIRECTIVES below except as noted herein. Any alterations to the product not agreed upon and directed by Biamp Systems Corporation will invalidate this declaration. ®... - Page 10 COMPLIANCE RoHS COMPLIANT This Biamp product, including all attendant cables and accessories supplied by Biamp, meets all requirements of EU Directives 2002/95/EC of January 27, 2003, and 2005/618/EC of August 18, 2005, the EU RoHS Directives. An EU RoHS Materials Content Declaration document may be obtained at www.biamp.com...
