- Page 1 AudiaEXPI-D & AudiaEXPO-D Digital Input & Output Expanders Operation Manual Biamp Systems, 10074 S.W. Arctic Drive, Beaverton, Oregon 97005 U.S.A. (503) 641-7287 www.biamp.com...
- Page 2 blank 16Mar07...
-
Page 3: Table Of Contents
Application pg. 6 remote locations. AudiaEXPI-D is represented as a block in AUDIA software, for easy inclusion into any system design. AudiaEXPI-D may also be used to Specifications pg. 8 provide inputs to other CobraNet compliant systems or devices. -
Page 4: Audiaexpi-D - Front & Rear Panels
(7) 'hops' (one-way transmissions) within a network. In order to integrate AudiaEXPI-D into a AUDIA system, an EXPI-D (or CobraNet) input block must first be placed into the design layout. AUDIA units intended to receive digital audio from the AudiaEXPI-D must have their CobraNet jacks connected to the same network. Both the AudiaEXPI-D unit (hardware) and the EXPI-D input block (software) must be assigned matching bundle numbers, before digital audio can be successfully exchanged. -
Page 5: Audiaexpo-D - Front & Rear Panels
Also, unicast and multicast bundle numbers can be used to access digital audio from individual or multiple EXPO-D output blocks. Similar considerations may apply when using AudiaEXPO-D with other CobraNet compliant systems or devices. AudiaEXPI-D and AudiaEXPO-D can exchange digital audio directly (outside of a system network) using either a simple 'cross-over' CAT5 cable or an... -
Page 6: Encoder/Display Menus
ENCODER/DISPLAY MENUS At power-up, the display will flash three product ID screens, ending on a customizable Title screen. Pressing the encoder while on the Title screen will reveal the Main Menu. Rotate encoder to cycle through available selections. Press encoder to make selections or enter data. MAIN MENU: COBRANET PARAMTRS - AES3 PARAMTRS - WORD CLK OUTPUT (EXPI-D only) - LOGIC PRESETS - PASSWORD PROTECT - TITLE DISPLAY - HARDWARE STATUS - ABOUT COBRANET PARAMTRS: Establishes CobraNet parameters for CURRENT operation and for LOGIC 1~8 (presets). - Page 7 ENCODER/DISPLAY MENUS WORD CLK OUTPUT (EXPI-D only): Selects word clock source for CURRENT operation and for LOGIC 1~8 (presets). ('CBRNET' default; 'INP 12'; 'INP 34'; 'INP 56'; 'INP 78') LOGIC PRESETS: Recalls LOGIC 1~8 presets into current settings or saves current settings into LOGIC 1~8 presets. RECALL - SAVE TO PASSWORD PROTECT: Sets and clears password protection.
-
Page 8: Application
Speakers (HF & LF), Balcony Speakers, Under-Balcony Speakers, Stage Monitors (1 & 2), Recording, and Hearing Assistance. Eight digital audio feeds, from mixing console outputs and other 'playback' devices, are connected to inputs of the AudiaEXPI-D unit, which is located near the mixing console. These signals are then sent via CobraNet to the AudiaFLEX unit, which is located backstage. The AudiaFLEX unit provides all necessary signal processing for each of the system outputs, before feeding an MCA8150 power amplifier located in the same equipment rack. - Page 9 & CobraNet media feeds EtherNet Switch AudiaFLEX 8-out CM 100-240V Installation Instructions: Telephone Interface TI-2 BIAMP SYSTEMS MODEL TI-2 BIAMP SYSTEMS CAUTION This device must be installed by qualified, trained personnel. 50/60Hz Serial Control Port ® US:6RMBR00BAUDIATI2...
-
Page 10: Specifications
SPECIFICATIONS AudiaEXPI-D SPECIFICATIONS Sample Rate: Logic Input Characteristics: TTL or contact-closure 48kHz CobraNet network 16kHz~96kHz 96kHz CobraNet network 32kHz~96kHz CobraNet I/O: 100Mb ethernet Bit Resolution (determined by input source or CobraNet): up to 24 bits Power Consumption (115/230VAC 50/60Hz): < 12 watts... -
Page 11: Block Diagrams
BLOCK DIAGRAMS EXPI-D Functional Block Diagram Cobranet Out Logic In Rotary Encoder Barrier Strip Cobranet Module display info audio Cobranet clock (48 / 96 kHz) Sample Sample Sample Sample clock source Rate Rate Rate Rate control Converter Converter Converter Converter Cobranet / Input clock word clocks... -
Page 12: Warranty
WARRANTY BIAMP SYSTEMS IS PLEASED TO EXTEND THE FOLLOWING 5-YEAR LIMITED WARRANTY TO THE ORIGINAL PURCHASER OF THE PROFESSIONAL SOUND EQUIPMENT DESCRIBED IN THIS MANUAL 1. BIAMP Systems warrants to the original purchaser of new THIS WARRANTY IS IN LIEU OF ALL OTHER products that the product will be free from defects in material WARRANTIES, EXPRESS OR IMPLIED.
