Page 1: Operation Manual
AudiaEXPI & AudiaEXPO Input & Output Expanders Operation Manual Biamp Systems, 10074 S.W. Arctic Drive, Beaverton, Oregon 97005 U.S.A. (503) 641-7287 www.biamp.com... - Page 2 blank 16Mar07...
-
Page 3: Table Of Contents
Specifications pg. 12 locations. AudiaEXPI is represented as a block in AUDIA software, for easy inclusion into any system design. AudiaEXPI may also be used to provide Block Diagrams pg. -
Page 4: Audiaexpi - Front & Rear Panels
Peak Indicators flash only on occasional peaks. Rotary Encoder & LCD Display: This control and display are used for initial setup of the AudiaEXPI unit. When power is first applied to the unit, the display will cycle through a product description, followed by a title screen. Press the control to enter setup. Rotate the control to make a selection, then press the control again to edit that selection. -
Page 5: Audiaexpo - Front & Rear Panels
Rotary Encoder & LCD Display: This control and display are used for initial setup of the AudiaEXPI unit. When power is first applied to the unit, the display will cycle through a product description, followed by a title screen. Press the control to enter setup. Rotate the control to make a selection, then press the control again to edit that selection. -
Page 6: Applications
(speech related) 70 volt distibuted speaker system in each of the four rooms. CobraNet from the AudiaEXPI units to the AudiaFLEX unit is tied together through an Ethernet switch. This allows sharing of digital audio signals (CobraNet) on a network. The maximum distance between any AUDIA unit and an Ethernet switch is 300 feet. Therefore, this system can span up to 600 feet between the main equipment rack and any of the rooms. - Page 7 Room D 1 & 2 CobraNet inputs AudiaFLEX 10x12 CM 100-240V Installation Instructions: Telephone Interface TI-2 BIAMP SYSTEMS MODEL TI-2 BIAMP SYSTEMS CAUTION This device must be installed by qualified, trained personnel. 50/60Hz Serial Control Port ® US:6RMBR00BAUDIATI2 designed and assembled in the USA RISK OF ELECTRICAL SHOCK.
- Page 8 APPLICATIONS Courthouse with Multiple Courtrooms and Hard-Disk Court Recording This application demonstrates the use of AUDIA in a Courtroom A Courtroom B modern courthouse. This is a networked system using two AudiaFLEX 20x4CM units and two AudiaEXPO 8-Output Expander units (forty inputs, distributed 70V distributed 70V twenty-four outputs, CobraNet).
- Page 9 Courtroom B mics Courtroom A mics AudiaFLEX 20x4 CM 100-240V Installation Instructions: Telephone Interface TI-2 BIAMP SYSTEMS MODEL TI-2 BIAMP SYSTEMS CAUTION Serial Control Port This device must be installed by qualified, trained personnel. US:6RMBR00BAUDIATI2 designed and assembled in the USA 50/60Hz ®...
- Page 10 APPLICATIONS Hospital with Multiple Zones of Paging, Messaging, and Background Music This application demonstrates the use of AUDIA in a 4th Floor multi-zone hospital building. This is a networked system using one AudiaFLEX 8x8CM unit and three AudiaEXPO 8-Output Expander units (eight inputs, Zone 1 Zone 2 Zone 3...
- Page 11 2nd Floor telephone page 3rd Floor telephone page 4th Floor telephone page AudiaFLEX 8x8 CM 100-240V Installation Instructions: Telephone Interface TI-2 BIAMP SYSTEMS MODEL TI-2 BIAMP SYSTEMS CAUTION Serial Control Port This device must be installed by qualified, trained personnel. US:6RMBR00BAUDIATI2...
- Page 12 Of course, all live mixing is done at the console. The AUDIA network provides transportation, routing, and processing of the signals. AudiaEXPI and AudiaEXPO units act as a 'digital snake', transmitting digital audio between the stage and mixing position. The AudiaFLEX unit provides routing and remote control capabilites, as well as signal processing for the speaker outputs.
- Page 13 1 2 3 4 5 6 7 8 EtherNet Switch from Mixer outputs 1~8 AudiaFLEX 2x8 CM 100-240V Installation Instructions: Telephone Interface TI-2 BIAMP SYSTEMS MODEL TI-2 BIAMP SYSTEMS CAUTION Serial Control Port This device must be installed by qualified, trained personnel. 50/60Hz ®...
-
Page 14: Specifications
SPECIFICATIONS AudiaEXPI SPECIFICATIONS Frequency Response (20Hz~20kHz @ -20dBFS): +0/-0.4dB Maximum Input (mic/line): +20dBu THD+N (20Hz~20kHz @ -20dBFS): Phantom Power: +48 VDC (10mA/input) line level (0dBu) < 0.006% Input Gain Range (variable trim): 0dB ~ +60dB mic level (-60dBu) < 0.065%... -
Page 15: Block Diagrams
BLOCK DIAGRAMS AudiaEXPI BLOCK DIAGRAM LCD & Logic encoder Processor Inputs Analog Inputs CobraNet Trim CM-1 digital audio & Peak AudiaEXPO BLOCK DIAGRAM LCD & Logic encoder Processor Inputs Analog Outputs CobraNet CM-1 Trim digital audio... -
Page 16: Warranty
WARRANTY BIAMP SYSTEMS IS PLEASED TO EXTEND THE FOLLOWING 5-YEAR LIMITED WARRANTY TO THE ORIGINAL PURCHASER OF THE PROFESSIONAL SOUND EQUIPMENT DESCRIBED IN THIS MANUAL 1. BIAMP Systems warrants to the original purchaser of new THIS WARRANTY IS IN LIEU OF ALL OTHER products that the product will be free from defects in material WARRANTIES, EXPRESS OR IMPLIED.
