Summary of Contents for Biamp Tesira EX-MOD
- Page 1 Tesira Modular Expander (EX-MOD) OPERATION MANUAL April 2019...
- Page 2 EX-MOD PRODUCT DESCRIPTION The Tesira® EX-MOD is a modular expander device that is designed for use with Tesira SERVER, SERVER-IO, and TesiraFORTÉ AVB devices. It can be configured with up to three 4-channel input and/or output expander cards for a maximum of 12 channels of I/O.
- Page 3 EX-MOD FRONT PANEL Setup and Use The Tesira software provides an intuitive interface for setup and programming of the EX-MOD. The information supplied by this manual relates to physical connections and device setup. For more details on software setup, please consult the Tesira Help File.
- Page 4 EIC-4 Card The Tesira EIC-4 is an expander card with four analog input channels for use with the Tesira EX-MOD device. The EIC-4 is one of three optional cards that can be mounted in Tesira EX-MOD. Each EIC-4 provides four channels of mic/line level audio input.
