Vocia
®
VO-4e
Operation Manual
January 2013
Biamp Systems, 9300 SW Gemini Drive, Beaverton, Oregon 97008 U.S.A. (503) 641-7287 www.biamp.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vocia VO-4e and is the answer not in the manual?

Questions and answers

Summary of Contents for Biamp Vocia VO-4e

  • Page 1 Vocia ® VO-4e Operation Manual January 2013 Biamp Systems, 9300 SW Gemini Drive, Beaverton, Oregon 97008 U.S.A. (503) 641-7287 www.biamp.com...
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 10) Protect the power cord from being walked on or pinched particularly at plugs, 2) Keep these instructions. convenience receptacles, and the point 3) Heed all warnings. where they exit from the product. 4) Follow all instructions.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS VOCIA OUTPUT 4 UNIT WITH EXTENDED CAPABILITY (VO-4e) . . . . . . . . . . . . . . . . 4 FEATURES .
  • Page 4: Vocia Output 4 Unit With Extended Capability (Vo-4E)

    • CobraNet audio/control with dynamic use of available bundles over single Ethernet cable • Dual CobraNet ports for redundancy • Rotary switches for device identification • IP30 Compliant •  CE marked, UL listed and RoHS compliant • 19 inch, 1RU housing • Covered by Biamp Systems’ 5-year warranty...
  • Page 5: Front Panel

    VO-4e FRONT PANEL Setup and Use The Vocia software provides the interface for configuring and programming the VO-4e. The information supplied by this manual relates to hardware installation, physical connections, device and channel failover concerns. For more details on software setup, please consult the Vocia Software Help File.
  • Page 6: Rear Panel

    VO-4e REAR PANEL Connections All numbered audio, relay and power connectors on the rear panel of the unit are configured with the lowest output or input on the left of the connector as viewed from the rear of the unit. Auxiliary Power Caution - Due to potential energy hazard, connections to the Auxiliary Power 24V DC inputs must be made by a qualified electrician or other qualified person as ...
  • Page 7: Led Indication

    VO-4e REAR PANEL CobraNet LED indication Left LED Right LED Description None None No Data Connectivity or CobraNet activity None Flashing green Network Link established. Typically seen on Secondary port when acting as a failover to the Primary connection. Yellow Flashing green Network Link established.
  • Page 8: Amp Fault Inputs

    VO-4e REAR PANEL Amp Fault Imputs Four amplifier Fault Inputs are provided via a six-way 0.2” (5.08mm) pluggable screw terminal block. These allow for fault monitoring of the output of the VO-4e as indicated from an external amplifier. By default each input allows an external voltage-free contact closure to ground to indicate a fault condition for the corresponding VO-4e Output channel.
  • Page 9: Failover Modes

    VO-4e REAR PANEL Failover Modes Device-to-Device or Channel-to-Channel failover modes are supported. Only one type of failover mode can be implemented per device. Device-to-Device Failover VO-4e units provide for Device-to-Device failover when a fault is detected. A Failover Link Cable must be connected between the primary and the redundant units as shown below.
  • Page 10: Specifications

    VO-4e SPECIFICATIONS Vocia Output 4e SPECIFICATIONS Message Memory: 5.625 MB Page Active Relays & Control Out Relays: Network Audio: 20-bits, 48kHz, 5-1/3 ms (fixed) Type: Single Form C voltage Network Connections: Dual RJ45 with shielded Ethernet cable free change over contact (CAT5, CAT5e, CAT6, or CAT 7) Max Operating Voltage: 125V AC, 60V DC...
  • Page 11: Warranty

    9. Biamp systems shall not be liable for special, indirect, incidental, or consequential damages, including lost profits or loss of use arising out of the purchase, sale, or use of the products, even if BIAMP Systems was advised of the possibility of such damages.
  • Page 12: Fcc Compliance

    FCC COMPLIANCE FCC NOTICE - CLASS B DIGITAL DEVICE NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential as well as in a commercial environment.
  • Page 13: Ec Declaration

      EC Declaration of Conformity Biamp Systems Corporation, as manufacturer having sole responsibility, hereby declares that the following described product complies with the applicable provisions of the DIRECTIVES below except as noted herein. Any alterations to the product not agreed upon and directed by Biamp Systems Corporation will invalidate this declaration.
  • Page 14: Eu Rohs Compliant

    EU RoHS COMPLIANT This Biamp product, including all attendant cables and accessories supplied by Biamp, meets all requirements of EU Directives 2011/65/EU of 8 June 2011, the EU RoHS Recast. An EU RoHS Materials Content Declaration document may be obtained at www.biamp.com...
