8.4.2 Pin assignment of ports A and B
Copyright © Müller-Elektronik GmbH & Co.KG
Parameter
Storage temperature
Weight
Dimensions (W x H x D)
Protection class
EMC
ESD protection
Power input
Display
Processor
RAM
Boot USB
Internal clock
Keyboard
Outputs
Ports A and B are both CAN-interfaces.
Port B is not currently connected.
Pin assignment of the 9-pin D-sub port of the ISO agricultural machinery interface (CAN).
Pin no.: Signal:
1 CAN_L
Value
-30 - +80 °C
1.3 kg
220 x 210 x 95 mm
IP 54 in accordance with DIN 40050/15
In accordance with ISO 14982 / PREN 55025
In accordance with ISO 10605
At terminal: 30322511
without external equipment
At terminal: 30322512
without external equipment
VGA TFT colour display; display size (diagonal): 14.5 cm ; resolution:
640 x 480 pixels
32-bit ARM920T up to 400 MHz
64 MB SDRAM
128 MB
Buffered by capacitor, keeps the time for 2 weeks without an external
power supply.
17 keys plus rotary knob
2 x CAN
1 x USB
1 x RS232
2 x M12 for two analogue cameras (optional for item no.: 30322512)
Pin no.:
6
