6.2
Opening applications
Procedure
6.3
Segmentation of the display
Copyright © Müller-Elektronik GmbH & Co.KG
You can perform the following actions in the selection menu:
▪ Open an application.
▪ Display an application in the header of the split display.
1.
- Set which application is to be displayed in the header of the split display.
⇨ The function icon of the selected application is marked with a dot on the left hand side:
2. Start the application for the main display. There are several ways to do so:
With the rotary knob:
- Select the desired application
- Open the selected application
Using the function keys on the right hand side:
- Display the application shown next to the function icon.
⇨ Both applications will appear on the display.
The display of the terminal BASIC-Terminal is split into two sections.
A different application is diplayed in each section. This allows you, for example, to control the tractor
on the field and monitor the field sprayer at the same time. This means that you will not need an
additional terminal.
Segmentation of the display
Header – section used to display information.
The header allows you to display information
about an application.
Opening applications in the selection menu
Opening applications
Main display – section used for control.
The main display shows the application
currently running, function icons and the
information you need to control the application
that is currently running.
6
21
