5 Basic control principles
5.1 Getting to grips with the controls
Controls
Copyright © Müller-Elektronik GmbH & Co.KG
Terminal controls
Rotary knob
Function keys
Rotary knob
The rotary knob is located in the top right hand corner of the terminal.
Control with the rotary knob may vary slightly between the different applications.
You can use the rotary knob to perform the following actions:
Turning the rotary knob:
▪ Move the cursor up and down.
▪ Change a parameter value.
Pressing the rotary knob:
▪ Click on the selected line.
▪ Activate parameter.
▪ Confirm input.
Function keys
Operating the function keys is the same across all applications.
Performing the functions depicted on the display
Basic control principles
Getting to grips with the controls
Keys
5
15
