Example
5.3 Initial start-up
Procedure
Copyright © Müller-Elektronik GmbH & Co.KG
Using the function keys
Function icon
Depiction of an available function.
When you press the function key
activated.
If not function icon appears next to a function key, this means that this function key has no function at
present.
1. Installing and connecting the terminal.
2. - Switch on the terminal.
3. Wait for approx. 15 seconds until all applications have been loaded.
4. - Open the "Selection menu" application.
⇨ The following screen will appear:
Function key
Performs the function depicted on the function
icon.
, the function depicted on the function icon
Basic control principles
5
Initial start-up
will be
17
