Configuring the terminal in the Service application

7.1

Controls in the Service application

Controls
Copyright © Müller-Elektronik GmbH & Co.KG
In the "Service" application you can configure the terminal and activate the connected farm
equipment.
Once you have started the "Service" application, the following screen will appear:
Start screen of the "Service" application
Main section
Screen contents
Version number
Name of the terminal and version of the
installed software
The "Service" application is controlled using the rotary knob and the function keys.
Some of the function icons explained here will only appear if a specific function is activated. This
limits the information shown on the display to just the information that you need for your work.
Function icon Meaning
Scroll
Back
Activate day mode
Activate night mode
File cannot be deleted (grey)
Configuring the terminal in the Service application
Controls in the Service application
Cursor
Selects a line that can be clicked on with the
rotary knob
Function icons section
Icons that can be pressed on this screen.
Appears only if...
There is one more page with
function icons.
Selected object cannot be
deleted
