Aeotec
Dual Nano Switch
SKU: AEOEZW140

Quickstart

This is a secure On/Off Power Switch for Europe. To run this device please connect it to your mains power supply. Turn the primary controller of Z-Wave
network into inclusion mode, short press the product's Action button that you can find on the product's housing.

What is Z-Wave?

Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.
(For more information about frequency regulations please refer to
Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and
every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is
not in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified
Z-Wave device regardless of brand and origin as long as both are suited for the same frequency range.
If a device supports secure communication it will communicate with other devices secure as long as this
device provides the same or a higher level of security. Otherwise it will automatically turn into a lower level
of security to maintain backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.

Product Description

Aeotec Dual Nano Switch is a Z-Wave Smart Switch specifically used to enable Z-Wave command and control (on/off) of any wall switches. In the event of power
failure, non-volatile memory retains all programmed information relating to the unit's operating status. It can connect to 2 external manual switches to control the
load ON/OFF independently. Its surface has a pin socket, which can be used for connecting to the touch panel, so you can also use the touch panel to control the
Dual Nano Switch. The Dual Nano Switch is also a security Z-Wave device and supports Over The Air (OTA) feature for the products firmware upgrade.

Prepare for Installation / Reset

Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You can do
this by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is recommended
to use the primary controller of the previous network to make sure the very device is excluded properly from this network.

Reset to factory default

This device also allows to be reset without any involvement of a Z-Wave controller. This procedure should only be used when the primary controller is inoperable.
Press and hold the Action button that you can find on the product's housing for 20 seconds and then release. This procedure should only be used when the
primary controller is inoperable.

Safety Warning for Mains Powered Devices

ATTENTION: only authorized technicians under consideration of the country-specific installation guidelines/norms may do works with mains power. Prior to the
assembly of the product, the voltage network has to be switched off and ensured against re-switching.

Installation

the frequency coverage overview at Sigma Designs Website
).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AEOEZW140 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aeotec AEOEZW140

  • Page 1: Product Description

    Product Description Aeotec Dual Nano Switch is a Z-Wave Smart Switch specifically used to enable Z-Wave command and control (on/off) of any wall switches. In the event of power failure, non-volatile memory retains all programmed information relating to the unit‘s operating status. It can connect to 2 external manual switches to control the load ON/OFF independently.
  • Page 2 Notes for the wire connection ports: N – Power input for neutral L – Power input for live IN – Input for load power supply OUT1 – Output for load 1 OUT2 – Output for load 2 S1 – External switch control for load 1 S2 –...
  • Page 3: Configuration Parameters

    Association - one device controls an other device Z-Wave devices control other Z-Wave devices. The relationship between one device controlling another device is called association. In order to control a different device, the controlling device needs to maintain a list of devices that will receive controlling commands. These lists are called association groups and they are always related to certain events (e.g.
  • Page 4 Setting Description Send Nothing Send Basic Set CC Parameter 82: To set which notification would be sent to the associated nodes in association group 4 To set which notification would be sent to the associated nodes in association Group 4 when using the external switch 2 to switch the loads. Size: 1 Byte, Default Value: 1 Setting Description...
  • Page 5: Technical Data

    Setting Description Enter automatic identification mode 2-state switch mode 3 way switch mode Momentary push button mode Parameter 121: Configure the external switch mode for S2. Configure the external switch mode for S2. Size: 1 Byte, Default Value: 0 Setting Description Enter automatic identification mode 2-state switch mode...
  • Page 6 Dimensions 0.0430000x0.0210000x0.0400000 mm Weight 33 gr Hardware Platform ZM5101 1220000015135 IP Class IP 20 Voltage 230 V Load 10 A Device Type On/Off Power Switch Network Operation Always On Slave Z-Wave Version 6.51.09 Certification ID ZC10-17035518 Z-Wave Product Id 0x0086.0x0003.0x008C Z-Wave Scene Type Scene Electric Load Type...
  • Page 7 Controller — is a Z-Wave device with capabilities to manage the network. Controllers are typically Gateways,Remote Controls or battery operated wall controllers. Slave — is a Z-Wave device without capabilities to manage the network. Slaves can be sensors, actuators and even remote controls. Primary Controller —...
